Quick Details
-
Theoretical Shot Volume(cm³):
-
59 cm³
-
Injection Rate (g/s):
-
60 g/s
-
Injection Weight (g):
-
56 g
-
Screw Speed (rpm):
-
0 - 250 rpm
-
Screw diameter (mm):
-
25 mm
-
Weight (KG):
-
1800 kg
-
Place of Origin:
-
Guangdong, China
-
Open Stroke(mm):
-
215 mm
-
Brand Name:
-
TES
-
Power (kW):
-
9 kW
Quick Details
-
Mold Height(mm):
-
140 - 200 mm
-
Ejector Stroke(mm):
-
120 mm
-
Ejector Force(kN):
-
17.2 kN
-
Theoretical Shot Volume(cm³):
-
59 cm³
-
Injection Rate (g/s):
-
60 g/s
-
Injection Weight (g):
-
56 g
-
Screw Speed (rpm):
-
0 - 250 rpm
-
Screw diameter (mm):
-
25 mm
-
Weight (KG):
-
1800 kg
-
Place of Origin:
-
Guangdong, China
-
Open Stroke(mm):
-
215 mm
-
Brand Name:
-
TES
-
Power (kW):
-
9 kW
GQ35 Manufacturing of vertical cables and plugs Injection moulding machines Plastic mesh cables Injection machine equipment
Key attributes
Other attributes
Condition
New
Style
VERTICAL
Injection Rate (g/s)
60 g/s
Machine Type
Hydraulic
Injection Weight (g)
56 g
Weight (KG)
1800 kg
Place of Origin
China
Warranty
1 Year
Key Selling Points
Easy to Operate
Applicable Industries
Manufacturing Plant
Showroom Location
None
Machinery Test Report
Provided
Video outgoing-inspection
Provided
Warranty of core components
1 Year
Core Components
Bearing, Motor, Pump, Gear, PLC, Other, Pressure vessel, Engine, Gearbox, Screw
Plastic Processed
PP, PC, ABS, PET, PVC, FRPP/PVC, PPR, HDPE, EPS, PA, PE, LDPE, HDPE/PP, ABS/PP, PE/PP, Polylactic Acid
Plasticizing Capacity(g/s)
45
Mold Height(mm)
1 -40 mm
Ejector Number
1
Ejector Stroke(mm)
120 mm
Ejector Force(kN)
17.2 kN
Theoretical Shot Volume(cm³)
59 cm³
Screw Speed (rpm)
0 - 250 rpm
Screw diameter (mm)
25 mm
Distance between Tie Bars
420*220mm
Type
Other
Open Stroke(mm)
215 mm
Model Number
GQ35T-C
Brand Name
TES
Power (kW)
5.5+3.6 kW
Product name
Plastic Injection Moulding Machine
Motor
2.2KW
Structure
Mechanical Vertical Compression
After-sales Service Provided1
Engineer Oversea Support
Application
PLASTIC ITEMS PRODUCING
Certification
CE ISO9001
Plastic Type
PE PP PA ABS PVC
Machine Color
Green+Red
Advantages
High Speed High Efficiency
Transport Package
Standard Packing
Specification
| MODEL | GQ35T-C | |||
| Screw diameter | mm | φ25 | φ28 | φ32 |
| Theoretical injction volume | cm³ | 59 | 74 | 96 |
| Injction weight | g(oz) | 56 | 70 | 91 |
| 2 | 2.5 | 3.2 | ||
| Max.Injection pressure | Mpa(kgf/cm²) | 2153 | 1715 | 1312 |
| Injection rate | mm³/s | 60 | 75 | 82 |
