Quick Details
-
Brand Name:
-
Runtx
-
Fork Length:
-
1150MM
-
Fork Width:
-
180MM
-
Overall Dimensions:
-
1791*797MM
-
Weight (KG):
-
4250 kg
-
Type:
-
Powered Pallet Truck
-
After-sales Service Provided:
-
Overseas third-party support available
-
Product Type:
-
Internal Combustion Counterbalanced Forklift
-
Color:
-
Red,Green
-
Feature:
-
Hydraulic Systems, Low Fuel Consumption, High Efficiency,Low Noise
-
Packing:
-
2pcs/pallet
-
Load Center:
-
500mm
-
Mast:
-
2 Stage/3 Stage
-
After Warranty Service:
-
Online support
Quick Details
-
Min. Lifting Height:
-
1955MM
-
Warranty:
-
1 Year
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
Runtx
-
Fork Length:
-
1150MM
-
Fork Width:
-
180MM
-
Overall Dimensions:
-
1791*797MM
-
Weight (KG):
-
4250 kg
-
Type:
-
Powered Pallet Truck
-
After-sales Service Provided:
-
Overseas third-party support available
-
Product Type:
-
Internal Combustion Counterbalanced Forklift
-
Color:
-
Red,Green
-
Feature:
-
Hydraulic Systems, Low Fuel Consumption, High Efficiency,Low Noise
-
Packing:
-
2pcs/pallet
-
Load Center:
-
500mm
-
Mast:
-
2 Stage/3 Stage
-
After Warranty Service:
-
Online support
Products Description
|
Manufacturer and specification
|
|
|
|
|
|
|
|
|||||||
|
1.1
|
Manufacturer
|
|
Runtx
|
|
|
|
|
|||||||
|
1.2
|
Model
|
|
CPD10
|
CPD15
|
CPD18
|
CPD20
|
CPD25
|
|||||||
|
1.4
|
Power type
|
|
Lead acid battery
|
|
|
|
|
|||||||
|
1.5
|
Rated capacity
|
|
1000
|
1500
|
1800
|
2000
|
2500
|
|||||||
|
1.6
|
Load center
|
|
500
|
500
|
500
|
500
|
500
|
|||||||
|
3.1
|
Tire type
|
|
Pneumatic
|
|
|
|
|
|||||||
|
3.3
|
Tires Size
|
|
16×6-8
15×4.5-8
|
6.50-10-12PR
5.00-8-8PR
|
|
23×9-10
18×7-8
|
|
|||||||
|
3.4
|
Driving brake
|
|
Hydraulic
|
|
|
|
|
|||||||
|
4.1
|
Tilting Angles
|
α/β（°）
|
6/12
|
6/12
|
6/12
|
6/12
|
6/12
|
|||||||
|
4.2
|
Height of lowered mast
|
mm
|
1875
|
1995
|
1995
|
1995
|
1995
|
|||||||
|
4.3
|
Max.lift height of mast
|
mm
|
3900
|
4025
|
4025
|
4045
|
4045
|
|||||||
|
4.4
|
Free lift height
|
mm
|
140
|
140
|
140
|
150
|
150
|
|||||||
|
4.7
|
Lift height of fork
|
mm
|
3000
|
|
|
|
|
|||||||
|
4.8
|
Front-wheel Overhead
|
mm
|
2100
|
2100
|
2100
|
2098
|
2098
|
|||||||
|
4.9
|
Length(without fork)
|
mm
|
1950
|
2035
|
2035
|
2353
|
2353
|
|||||||
|
4.10
|
Front overhang
|
mm
|
350
|
400
|
400
|
440
|
440
|
|||||||
|
4.11
|
Rear overhang
|
mm
|
300
|
335
|
335
|
384
|
384
|
|||||||
|
4.12
|
Wheelbase
|
mm
|
1200
|
1360
|
1360
|
1360
|
1500
|
|||||||
|
4.13
|
Min.ground clearance
|
mm
|
110
|
110
|
110
|
110
|
110
|
|||||||
Details
1. High-quality manganese steel, strong toughness and high safety factor
2. Electrophoresis-automotive grade painting process
3. Integral forming overhead guard, strong and durable, large arched structure, high pressure resistance, strong safety
4. Integrated injection molding instrument panel, humanized design, with USB charging port
5. With LED headlights, beautiful and practical, energy-saving more than 80%
6. High-frequency MOSFET integrated controller ensures smooth and precise walking and lifting control,excellent speed regulation
performance, good matching performance of motor electronic control, regenerative braking,reverse braking, slope anti-slide and
other functions, safe and reliable.
2. Electrophoresis-automotive grade painting process
3. Integral forming overhead guard, strong and durable, large arched structure, high pressure resistance, strong safety
4. Integrated injection molding instrument panel, humanized design, with USB charging port
5. With LED headlights, beautiful and practical, energy-saving more than 80%
6. High-frequency MOSFET integrated controller ensures smooth and precise walking and lifting control,excellent speed regulation
performance, good matching performance of motor electronic control, regenerative braking,reverse braking, slope anti-slide and
other functions, safe and reliable.
