Quick Details
-
Storage Type:
-
25°C
-
The charging ratio:
-
0.2C
-
The discharge rate:
-
10Hr/20Hr
-
Battery Size:
-
2V 200-3000Ah
-
Brand Name:
-
SunArk
-
Model Number:
-
SA2-200~SA2-3000
-
Place of Origin:
-
Anhui, China
-
Weight:
-
11-160KG
-
Cells Per Unit:
-
1
-
Voltage Per Unit:
-
2
-
Design Life:
-
15 Years (Float Charging)
-
Standby Use Voltage:
-
2.27V~2.30V @25°C
-
Cycle Use Voltage:
-
2.43V~2.47V @25°C
-
Operating Temperature Range:
-
Discharge: -20°C~60°C Charge: 0°C~50°C Storage: -20°C~60°C
-
Normal Operating Temperature Range:
-
25°C ± 5°C
-
Self Discharge:
-
Monthly Self-discharge Ratio Is Less Than 3% At 25°C.
-
Container Material:
-
A.B.S. UL94-HB, UL94-V0 Optional
Quick Details
-
Chargeable:
-
Yes
-
Battery Type:
-
AGM
-
Cycle Life:
-
2000@30%DOD
-
Storage Type:
-
25°C
-
The charging ratio:
-
0.2C
-
The discharge rate:
-
10Hr/20Hr
-
Battery Size:
-
2V 200-3000Ah
-
Brand Name:
-
SunArk
-
Model Number:
-
SA2-200~SA2-3000
-
Place of Origin:
-
Anhui, China
-
Weight:
-
11-160KG
-
Cells Per Unit:
-
1
-
Voltage Per Unit:
-
2
-
Design Life:
-
15 Years (Float Charging)
-
Standby Use Voltage:
-
2.27V~2.30V @25°C
-
Cycle Use Voltage:
-
2.43V~2.47V @25°C
-
Operating Temperature Range:
-
Discharge: -20°C~60°C Charge: 0°C~50°C Storage: -20°C~60°C
-
Normal Operating Temperature Range:
-
25°C ± 5°C
-
Self Discharge:
-
Monthly Self-discharge Ratio Is Less Than 3% At 25°C.
-
Container Material:
-
A.B.S. UL94-HB, UL94-V0 Optional
Product Description
|
Model
|
Nominal Voltage
|
Capacity
C10/1.8VPC
|
|
Dimension
|
|
|
|
||||
|
|
|
|
|
Length
|
Width
|
Height
|
Total Height
|
||||
|
|
V
|
Ah
|
|
mm/inch
|
mm/inch
|
mm/inch
|
mm/inch
|
||||
|
SA2-200
|
2
|
200
|
|
170/6.69
|
106/4.17
|
330/12.99
|
342/13.46
|
||||
|
SA2-250
|
2
|
250
|
|
170/6.69
|
106/4.17
|
330/12.99
|
342/13.46
|
||||
|
SA2-300
|
2
|
300
|
|
170/6.69
|
150/5.91
|
330/12.99
|
342/13.46
|
||||
|
SA2-400
|
2
|
400
|
|
170/6.69
|
150/5.91
|
330/12.99
|
342/13.46
|
||||
|
SA2-500
|
2
|
500
|
|
196/7.72
|
171/6.73
|
330/12.99
|
342/13.46
|
||||
|
SA2-600
|
2
|
600
|
|
241/9.49
|
171/6.73
|
330/12.99
|
342/13.46
|
||||
|
SA2-800
|
2
|
800
|
|
285/11.22
|
171/6.73
|
330/12.99
|
342/13.46
|
||||
|
SA2-1000
|
2
|
1000
|
|
383/15.08
|
171/6.73
|
330/12.99
|
342/13.46
|
||||
|
SA2-1200
|
2
|
1200
|
|
471/18.54
|
171/6.73
|
330/12.99
|
342/13.46
|
||||
|
SA2-1500
|
2
|
1500
|
|
355/13.98
|
337/13.27
|
330/12.99
|
342/13.46
|
||||
|
SA2-2000
|
2
|
2000
|
|
476/18.74
|
337/13.27
|
330/12.99
|
342/13.46
|
||||
|
SA2-2500
|
2
|
2500
|
|
476/18.74
|
337/13.27
|
330/12.99
|
342/13.46
|
||||
|
SA2-3000
|
2
|
3000
|
|
696/27.4
|
340/13.39
|
330/12.99
|
342/13.46
|
||||
