Quick Details
-
Brand Name:
-
FESU
-
Model Number:
-
FS024-04
-
Max. Current:
-
6(6)A, 10A
-
Certificate:
-
CQC TUV CE
-
Material:
-
Plastic
-
ELECTRICAL LIFE:
-
50000 Times
-
Certification:
-
CE, CQC, TUV
Quick Details
-
Whether the smart:
-
NO
-
Max. Voltage:
-
250VAC
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
FESU
-
Model Number:
-
FS024-04
-
Max. Current:
-
6(6)A, 10A
-
Certificate:
-
CQC TUV CE
-
Material:
-
Plastic
-
ELECTRICAL LIFE:
-
50000 Times
-
Certification:
-
CE, CQC, TUV
|
component materials: |
1. actuator :nylon |
|
2. housing :nylon |
|
|
3. spring :iron |
|
|
4. other component :copper |
|
|
electrical features: |
1.Optional rated current: 6A |
|
2. optional rated voltage:250V OR 125V |
|
|
3.frequency:50/60HZ |
|
|
4.electrical life:5E4 |
|
|
5. Certificated rating: 6(6)A,250V |
|
|
mechanical features: |
1. Mechanical contact system:SPNO |
|
2. Full wave variable speed control |
|
|
3.Optional with lock |
|
|
4.Optional the positive and reversing device. |
|
|
5.Optional trimmer pacer |
|
|
6.Optional half limit function |
|
|
7.Terminals: aperture 3mm; terminals insert :0.6*0.8mm |
|
|
8.Mechanical life:1E4 |
|
|
9. contact gap :upon users demand |
|
|
10. approval : TUV, CE, CQC |
|
|
11. trigger operating force:25N(MAX) release lock button |
|
|
12. lock on button force:20N |
|
|
installation: |
1. screw terminals accept stranded wire encapsulated with terminal pins |
