Quick Details
-
Model Number:
-
LEIA-X4
-
Place of Origin:
-
Shandong, China
-
Product Name:
-
Fluorescence Quantitative PCR Detection System
-
Sample Capacity:
-
96x0.1ml PCR plate, 12x8-strip tubes, 96*0.1ml single tube
-
Reaction System:
-
10~50μl
-
Dynamics Range:
-
1-1010copies
-
Channel:
-
4
-
Emission Light:
-
LED
-
Detector:
-
PD
-
Excitation Wavelength:
-
455~645nm
-
Detection Wavelength:
-
510~710nm
-
Scanning Mode:
-
Full plate scanning
Quick Details
-
Warranty:
-
1 Year
-
After-sale Service:
-
Online technical support
-
Brand Name:
-
BIOBASE
-
Model Number:
-
LEIA-X4
-
Place of Origin:
-
Shandong, China
-
Product Name:
-
Fluorescence Quantitative PCR Detection System
-
Sample Capacity:
-
96x0.1ml PCR plate, 12x8-strip tubes, 96*0.1ml single tube
-
Reaction System:
-
10~50μl
-
Dynamics Range:
-
1-1010copies
-
Channel:
-
4
-
Emission Light:
-
LED
-
Detector:
-
PD
-
Excitation Wavelength:
-
455~645nm
-
Detection Wavelength:
-
510~710nm
-
Scanning Mode:
-
Full plate scanning
If you'd like to know price, delivery time or more details,
please chat me or sent inquiry!
Product Description
Fluorescent Quantitative Detection System
Application:
It can be widely used for Infectious disease research, Food pathogen detection, Waterborne pathogen detection, Pharmaceutical analytics, Stem cell research, Pharmacogenomics research, Oncology and genetic disease research, Plant sciences and agricultural biotechnology.
Working principle:
The temperature step change is controlled by the semiconductor peltier to realize PCR amplification. Use high-sensitivity MPPC unit to detect fluorescence; Program control channel switching, non-contact excitation/detection on the top structure, coordinated with motor control x and Y axis movement to achieve 96-hole scanning. Finally, accurate analysis is carried out through powerful software.
It can be widely used for Infectious disease research, Food pathogen detection, Waterborne pathogen detection, Pharmaceutical analytics, Stem cell research, Pharmacogenomics research, Oncology and genetic disease research, Plant sciences and agricultural biotechnology.
Working principle:
The temperature step change is controlled by the semiconductor peltier to realize PCR amplification. Use high-sensitivity MPPC unit to detect fluorescence; Program control channel switching, non-contact excitation/detection on the top structure, coordinated with motor control x and Y axis movement to achieve 96-hole scanning. Finally, accurate analysis is carried out through powerful software.
Technical Parameters
|
Product Name
|
Fluorescence Quantitative PCR Detection System
|
|
|
|
|||
|
Model
|
LEIA-4X
|
|
|
|
|||
|
Sample Capacity
|
96x0.1ml PCR plate, 12x8-strip tubes, 96*0.1ml single tube (Transparent Cover)
|
|
|
|
|||
|
Reaction System
|
10~50μl
|
|
|
|
|||
|
Dynamics Range
|
1-1010copies
|
|
|
|
|||
|
Channel
|
4
|
|
|
|
|||
|
Emission Light
|
LED
|
|
|
|
|||
|
Detector
|
MPPC
|
|
|
|
|||
|
Detection Path
|
F1
|
F2
|
F3
|
F4
|
|||
|
Suitable Probe/Dye
|
FAM/SYBR GREEN
|
VIC/JOE/ HEX/TET
|
ROX/TEXAS-RED
|
Cy5
|
|||
|
Excitation Wavelength
|
455~680nm
|
|
|
|
|||
|
Detection Wavelength
|
510~730nm
|
|
|
|
|||
|
Fluorescence Detection Repeatability
|
CV≤2%
|
|
|
|
|||
|
Fluorescence Detection Accuracy
|
CV≤3%
|
|
|
|
|||
|
Fluorescence Detection Linearity
|
r≥0.995
|
|
|
|
|||
|
Module Temp. Range
|
4-99℃(resolution:0.1℃)
|
|
|
|
|||
|
Ramp Rate
|
5.0℃/s(max)
|
|
|
|
|||
|
Temp. Accuracy
|
±0.3℃
|
|
|
|
|||
|
Temp. Uniformity
|
≤ ±0.3℃
|
|
|
|
|||
|
Temp. Control Mode
|
Block mode
|
|
|
|
|||
|
Gradient Temp. Range
|
1-36℃
|
|
|
|
|||
|
Hot-Lid Temp. Range
|
100℃, Automatic Hot-lid
|
|
|
|
|||
|
Scanning Mode
|
Full plate scanning
|
|
|
|
|||
|
Programming
|
Max 100 Segments for Each Program, Max 99 Cycles
|
|
|
|
|||
|
Operation Mode
|
Continuous
|
|
|
|
|||
|
Scanning Time
|
8.5s
|
|
|
|
|||
|
Special Function
|
Absolute quantitative automatic analysis, relative quantification, SNP Analysis, melting curve analysis, etc.
|
|
|
|
|||
|
Operation System
|
Microsoft: Windows10
|
|
|
|
|||
|
Power Supply
|
220V,50/60HZ; 110V,60HZ
|
|
|
|
|||
|
Dimension(L*W*H) Mm
|
375*490 *365
|
|
|
|
|||
|
Port Method
|
USB Port
|
|
|
|
|||
|
Packing Size(L*W*H) Mm
|
645*565 *605
|
|
|
|
|||
|
Gross Weight
|
45
|
|
|
|
|||
