European Superior marine floating dock floating dock foam blocks plastic floating dock pier

marine floating dock floating dock foam blocks plastic floating dock pier 500*500*400mm:

marine floating dock floating dock foam blocks plastic floating dock pier 1000*500*400mm :

marine floating dock floating dock foam blocks plastic floating dock pier 1500*500*400mm:

Floating walkway,the floating walkway is composed by pontoon cubes and accessories:

Buoy use for Floating swimming pools and Aquaculture:

Application:

Load Capacity:

each one square meter is made up of four pontoons, top load is 325kgs.
Draft without load: 2.5-3cm;
Draft with load of 150kgs: 15-20cm(safe);
Draft with load of 300kgs:35-40cm(load limit)

Anti Wind Wave:

1.The wave on water surface between 2-class and 3-class belongs to safe applicable range.
2.The wave on water surface between 3-class and 6-class can be applicable; however,the safety protection must be reinforced.
3.The wave on water surface between 6-class and 9-class is the restricted applicable range (it is suggested that the shipping shall not be parked and the visitors shall not be in or out).
Attention: to avoid shaking of the dock, the area of internal lake’s dock is not less than 30 square meter; the area of stage is not less than 100 square meter.

Anchoring:

1.If water is less than 3m in depth, steel piles are to be put in proper place and then connected by wheels, which can prevent the floating dock from moving laterally but can automatically rise and fall in line with water level.
2.If water is over 3m in depth, anchoring can be used by sinking the anchorage block pulled by steel cables to the water bottom.

Guarantee:

warranty on our floats are 3 years, that is within three years, if there is any damage caused by the product in normal condition, we will replace the floats for you.

Production line:

Workflow:

Project plan design→Raw material →Manufacturer →Delivery →Installation →Completion

Attention:

Our pontoons production capacity is 5200sqm/month at least .

Our Advantages for marine floating dock floating dock foam blocks plastic floating dock pier:

1,4 years professional manufacturer for plastic products.

2,Our products safe,durable and environmentally friendly.

3,Easy installing and dismantling.

4,A wide range,high quality,reasonable price and stylish designs.

5,Can accept custom design.

6,Fast delivery.

Quadrate circular aquaculture Trap

Fish farm cage

Circular cage

Square cage

Submersible and rising cage

Sea cucumber cage

Recreation fishery facilities/floating cage

Cage accessories

The net clothing:Twisted net, Polyethylene net, Nylon net for fish fry

Anchoring and accessories

Square cage

Square cage

Round cage

RAYEE's advantage

- No agents to pay. You're working direct with the manufacturer to have the best possible price.
- You won't approve a good sample but get a container load of inferior shipment many months later.
- Guranteed lead times at MAX four weeks from order to shipment, often much faster.
- Extensive range of weight /colour options to suit most requirements, or we can manufacture to your specification.
- We have our own weaving machines and experienced workers with more than 10 years skill at marine floating dock floating dock foam blocks plastic floating dock pier lines.
