Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Hepburn
-
Model Number:
-
Round bars
-
Heat treatment:
-
Annealed; Q+T
-
Process:
-
EAF or ESR
-
Annealing, max hardness:
-
215HB
-
Hardness after quenching:
-
52-56HRC
-
UT test:
-
Per standard of SEP 1921-84, 100% Volume. Lecel C/c, D/d or E/e
-
Payment terms:
-
T/T;LC
-
Lead time:
-
10-15 days
Quick Details
-
Steel Grade:
-
4Cr13
-
Tolerance:
-
±10%
-
Grade:
-
steel
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Hepburn
-
Model Number:
-
Round bars
-
Heat treatment:
-
Annealed; Q+T
-
Process:
-
EAF or ESR
-
Annealing, max hardness:
-
215HB
-
Hardness after quenching:
-
52-56HRC
-
UT test:
-
Per standard of SEP 1921-84, 100% Volume. Lecel C/c, D/d or E/e
-
Payment terms:
-
T/T;LC
-
Lead time:
-
10-15 days
S136 AISI 420 1.2083 Plastic Mould Steel which made in China
| Steel Grade | GB 4Cr13 / DIN 1.2083 / AISI 420 / JIS SUS420 / S136 |
| Processing Technic | EAF or ESR material, Hot rolled or hot forged |
|
Size & Dimension |
Diameter: Φ60mm~Φ350mm, Length: 1m~9m (Customized size acceptable) |
| Inspection | UT before delivery, third party inspection like SGS, TUV, and so on |
| Surface | Black, Grined or Turned bright |
| Heat treatment | Annealing HBS<215 Hardness after quenching: 52 - 56 HRC |
|
C |
Si ≤ |
Mn ≤ |
P≤ |
S≤ |
Cr |
|
0.36-0.42 |
1.00 |
1.00 |
0.030 |
0.030 |
12.5-14.5 |
Material character:
Martensitic stainless chromium steel for plastic moulds, excellent polishability and corrosion resistance in hardened condition, high wear resistance, high compression strength, through hardening, low distorsion, good machinability and photoetching properties. This grade can be produced on request by the process ESR and quenched and tempered condition.
Moulds for corrosive plastic materials such as PVC, recycled polymers etc., moulds for chemically aggressive plastics andp lastics containing abrasive fillers, mould inserts, dies and gauges for PVC extrusions, screws and barrels for extruders, moulds for automotive, food, medical and optical industry such as spectacles, compact discs, lenses.
Delivery time
15 days after order confirmed.
Packing details
Standard seaworthy packing or as customer required
Payment
T/T or L/C at sight.
