Quick Details
-
Warranty:
-
12 years
-
Brand Name:
-
Trina, Trina solar panel
-
Model Number:
-
Trina***MBAP-144-D
-
Place of Origin:
-
Shandong, China
-
Panel Dimensions:
-
2279*1134*30mm
-
Application:
-
Solar Power System
-
Frame:
-
Anodized Aluminium Alloy
-
Glass:
-
Single Glass
-
Material:
-
Monocrystaline Silicon
-
Solar panel:
-
High Efficinency Transparent Solar Panel
-
Solar cell:
-
A-grade
-
Weight:
-
32.7kg
-
Junction Box:
-
IP68
-
Color:
-
Blue
-
Certificate:
-
CE/CQC/TUV/ISO
Quick Details
-
Cell size:
-
182mmx182mm
-
Type:
-
PERC, Half Cell, Double-glass, MWT, IBC, HJT, hbc, N-TYPE, TOPCON, BIPV
-
Panel Efficiency:
-
21.5%
-
Warranty:
-
12 years
-
Brand Name:
-
Trina, Trina solar panel
-
Model Number:
-
Trina***MBAP-144-D
-
Place of Origin:
-
Shandong, China
-
Panel Dimensions:
-
2279*1134*30mm
-
Application:
-
Solar Power System
-
Frame:
-
Anodized Aluminium Alloy
-
Glass:
-
Single Glass
-
Material:
-
Monocrystaline Silicon
-
Solar panel:
-
High Efficinency Transparent Solar Panel
-
Solar cell:
-
A-grade
-
Weight:
-
32.7kg
-
Junction Box:
-
IP68
-
Color:
-
Blue
-
Certificate:
-
CE/CQC/TUV/ISO
Product Description
Monocrystalline half cut
high efficiency solar panel
Increase generating power by 10%
Battery conversion efficiency 21.19%
166*166mm 10MBB
Low operating temperature and strong resistance to hot spot
166mm multi main grid (MBB) battery and semi slicing technology
low current operation
high power output
specification
|
Electrical performance parameters under STC
|
|
|
|
|
|
|
|
|
||||||||
|
Model ：TW***MBAP-144-D
|
|
|
|
|
|
|
|
|
||||||||
|
Maximum power Pmax[W]
|
520
|
525
|
530
|
535
|
540
|
545
|
550
|
555
|
||||||||
|
Open circuit voltage Voc[V]
|
48.45
|
8.49
|
48.68
|
8.96
|
9.24
|
9.52
|
49.8
|
50.08
|
||||||||
|
Short circuit current Isc[A]
|
13.59
|
13.63
|
13.68
|
13.73
|
13.78
|
13.83
|
13.88
|
13.93
|
||||||||
|
Voltage at maximum power point Vmp [V]
|
40.5
|
40.73
|
40.96
|
41.22
|
41.45
|
41.7
|
41.93
|
42.18
|
||||||||
|
Current at maximum power point Imp [A]
|
12.84
|
12.89
|
12.94
|
12.98
|
13.03
|
13.07
|
13.12
|
13.16
|
||||||||
|
Component efficiency [%]
|
20.1
|
20.3
|
20.5
|
20.7
|
20.9
|
21.1
|
21.3
|
21.5
|
||||||||
|
Electrical performance parameters under NMOT
|
|
|
|
|
|
|
|
|
||||||||
|
Maximum power Pmax[W]
|
393.5
|
397.3
|
401.1
|
404.8
|
408.6
|
412.4
|
416.2
|
420
|
||||||||
|
Open circuit voltage Voc[V]
|
45.74
|
45.77
|
45.95
|
46.21
|
46.48
|
46.74
|
47.01
|
47.28
|
||||||||
|
Short circuit current Isc[A]
|
10.88
|
10.92
|
10.96
|
11.00
|
11.04
|
11.08
|
11.12
|
11.16
|
||||||||
|
Voltage at maximum power point Vmp [V]
|
37.56
|
37.78
|
38.00
|
38.23
|
38.45
|
38.67
|
38.9
|
39.12
|
||||||||
|
Current at maximum power point Imp [A]
|
10.47
|
10.51
|
10.54
|
10.58
|
10.62
|
10.66
|
10.7
|
10.74
|
||||||||
|
Module nominal operating temperature (NMOT): irradiance=800W/m2, ambient temperature=20 ℃, AM=1.5, wind speed: 1m/s
|
|
|
|
|
|
|
|
|
||||||||
