Quick Details
-
Passenger capacity:
-
2
-
Max. loading weight:
-
270kgs
-
Overall dimensions (mm):
-
2410x1180x1800
-
Min. ground clearance (mm):
-
120
-
Front wheel tread (mm):
-
1010
-
Rear wheel tread (mm):
-
1010
Quick Details
-
Power:
-
> 1000W
-
Place of Origin:
-
Jiangsu, China
-
Model:
-
EG202AK
-
Passenger capacity:
-
2
-
Max. loading weight:
-
270kgs
-
Overall dimensions (mm):
-
2410x1180x1800
-
Min. ground clearance (mm):
-
120
-
Front wheel tread (mm):
-
1010
-
Rear wheel tread (mm):
-
1010
Product Description
| Model+A1A1:F18 | EG202AK | ||||
| System | 36V/3KW Sepex | 48V/4KW Sepex |
48V/4KW Sepex |
48V/4KW AC system |
48V/4KW AC system |
| Key Components | |||||
| Battery |
6PCSxT105 (185Ah@5hr rate) |
6PCSxT875 (145Ah@5hr rate) |
8PCSxT105 (185Ah@5hr rate) |
6PCSxT875 (145Ah@5hr rate) |
8PCSxT105 (185Ah@5hr rate) |
| Motor | 3KW ADC |
3.8KW Chinese motor |
3.8KW Chinese motor |
3.8KW AC motor | 3.8KW AC motor |
| Controller | Curtis 1243 (300A@2minutes) | Curtis 1268 (400A@2minutes) | Curtis 1268 (400A@2minutes) | Zapi ACE0 (280A@2minutes) | Zapi ACE0 (280A@2minutes) |
| Performance | |||||
| Passenger capacity | 2 | 2 | 2 | 2 | 2 |
| Range (loaded) based on flat road at a speed of 30km/h (km) * | >55 | >65 | >80 | >70 | >100 |
| Max. speed @12.76:1 gear ratio | 23 | 32 | 32 | 32 | 32 |
| Minimum turning radius (m) | 3 | 3 | 3 | 3 | 3 |
| Max. climbing ability (loaded) @ 12.76:1 gear ratio | 20% | 25% | 25% | 25% | 25% |
| Max. movement after brake at speed of 20km/h | ≤4m | ≤4m | ≤4m | ≤4m | ≤4m |
| Max. loading weight | 270kgs | 270kgs | 270kgs | 270kgs | 270kgs |
| Net weight | 455kgs | 465kgs | 515kgs | 460kgs | 510kgs |
| Dimensions | |||||
| Overall dimensions (mm) | 2410x1180x1800 | ||||
| Min. ground clearance (mm) | 120 | ||||
| Wheelbase (mm) | 1680 | ||||
| Front wheel tread (mm) | 1010 | ||||
| Rear wheel tread (mm) | 1010 | ||||
