- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
Jushixin
-
Product name:
-
Vacuum Sewage Suction Truck
-
Drive type:
-
4x2/6x2/6x4/8x4/8x6/4x4/6x6/etc
-
Engine:
-
Weichai
-
Keyword:
-
Vacuum Sewage Truck Pump
-
Volume:
-
10CBM
-
Chassis brand:
-
Howo ,Shacman,Dongfeng,Isuzu
Quick Details
-
Size:
-
8900*2500*3300
-
Gross Vehicle Weight:
-
18000
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
Jushixin
-
Product name:
-
Vacuum Sewage Suction Truck
-
Drive type:
-
4x2/6x2/6x4/8x4/8x6/4x4/6x6/etc
-
Engine:
-
Weichai
-
Keyword:
-
Vacuum Sewage Truck Pump
-
Volume:
-
10CBM
-
Chassis brand:
-
Howo ,Shacman,Dongfeng,Isuzu
| Overall dimension(mm) | 8900×2500×3300 |
| Volume | 16 m³ |
| Total weight(kg) | 18000 |
| Cab | Flat roof cab,Dongfeng Tianjin cab,Reversible, with air conditioning |
| Front axle | 9 T |
| Rear axle | 13 T |
| Gear Box | Shaanxi tooth 8 gear box |
| Frame | Straight reinforced girder |
| Tire | 10.00R20 steel wire tyres 10 |
| ABS | Have |
| PTO connector | Have |
| PTO | Have |
| Front / rear suspension (mm) | Front:1430,Rear:2970 |
| Departure corner | Front:20,Rear:17 |
| suspension | Leaf spring 8/10+8 |
| Axle number | 3 |
| Wheelbase | 4500mm |
| Track | 1870/1820mm |
| Driving type | 4*2 |
| Engine | EQB190 20 |
| Emission standard | Euro 2 |
| Brake | Drum type |
| Braking System | Air brake |
| Driving form | Steering Wheel / Left Drive |
| Upper part configuration | |
| Item | Specification |
| Garbage box material and thickness | Q345 Low alloy anti-corrosion wear plate (manganese steel), 5mm edge, 5mm bottom, 5mm side plate |
| compartments body shape | Curved box body |
| Emergency stop button | Have |
| Safety control system | Have |
| The sewage tank | Have |
| Tail control unit | Have |
| Remark: Adopt domestic famous brand oil cylinder, high density high pressure oil pipe, multi-way valve and oil pump, small bucket turn over.The compressed dustbin is a conjoined type, working with external power supply, inverted feeding, with compression push plate and locking door at the rear. | |
Product Description
1. Making garbage collection simple: change the dirty appearance of the city and eliminate the secondary pollution;
2. High compression ratio and large loading capacity which is 2 times larger than usual garbage truck;
3. Easy Full Automatic Operation: electrical control system for loading and unloading operations.
4. One Person Operation: Reducing sanitation work, greatly improves the working efficiency.
5. Double Operation System: electrical control system and manual operation greatly improves the vehicle usage rate.
1.With well experienced feed truck production company to offer high quality and competitive prices dump truck to our worldwide valuable customers.
2.An professional team which is experienced with international market and has strong technical capability to customized cost effective,because we have more than 60 Designer and engineers as our solid backing.Among them,our technical adviser has more than 40years' experience in the dump truck field.
3.Sell well in the international markets, such as African market ( Sudan, Angola, Zimbabwe, Liberia, Djibouti, Congo, Kenya, Ghana ect.), Middle East, South Asia and South-America market etc..
4.Two Years Guarantee for all the the beam of trailers, timely shipment.
Q1. What's your MOQ?
One unit trailer or truck.
Q2. Can you satisfy my special requirement?
Definitely! We are direct manufacturer and we have strong producing capacity and R&D capacity!
Q3.How about your product quality?
High quality has always been our advantage.We all use high quality brand materials with 100% quality assurance.Established a procedure to check products at all stages of the manufacturing process,raw materials,process materials,validated or tested materials finished goods ect.
Q4. How can I get the price of your truck?
You can contact with us through any of the following contact information. Our personalized service person will respond you within 24 hours.
Q5: What's the delivery time?
The delivery time is within 30-50 working days after receiving your advance payment.
