Quick Details
-
Size:
-
50.8*39.8*91.9mm
-
Place of Origin:
-
Shandong, China
-
Axle:
-
FUWA
-
Product name:
-
Fuel Tanker Trailer
-
Suspension:
-
Mechanical Suspension
-
Tire:
-
12R22.5
-
King pin:
-
2"(50mm)or3.5"(90mm) JOST
-
Capacity:
-
30T-90T
-
Volume:
-
70000liter Max
-
Loading capacity:
-
30T~ 60T
-
Color:
-
Customers Optional
-
Transport:
-
Bulk Cargo Sand Grain
Quick Details
-
Type:
-
Full Trailer
-
Max Payload:
-
<5000 kg
-
Brand Name:
-
LUEN
-
Size:
-
50.8*39.8*91.9mm
-
Place of Origin:
-
Shandong, China
-
Axle:
-
FUWA
-
Product name:
-
Fuel Tanker Trailer
-
Suspension:
-
Mechanical Suspension
-
Tire:
-
12R22.5
-
King pin:
-
2"(50mm)or3.5"(90mm) JOST
-
Capacity:
-
30T-90T
-
Volume:
-
70000liter Max
-
Loading capacity:
-
30T~ 60T
-
Color:
-
Customers Optional
-
Transport:
-
Bulk Cargo Sand Grain
Title goes here.
The air compressor is perfectly matched with the tank body, the piping system design is advanced, and the discharge speed is fast.
The inside of the tank adopts advanced fluidized tube structure, the internal chute has a large angle and low residual rate.
The inside of the tank adopts advanced fluidized tube structure, the internal chute has a large angle and low residual rate.
|
Brand
|
LUEN
|
|
|
Maximum load
|
30T
|
|
|
Length * Width *Height(mm)
|
8800* 2500*4000
|
|
|
Axle
|
LH 13T American Type Axle *3
|
|
|
Suspension
|
LH 13T*3 Three axis Mechanical Suspension
|
|
|
Volume
|
28 CBM
|
|
|
King Pin
|
2"/3.5" welding / assembly
|
|
|
Landing Gear
|
28T linkage / single action
|
|
|
Tire /Rim
|
11.00R20/12.00R22.5 *12
|
|
|
Stringer(工-beam)
|
Thickness of upper wing: 10mm
|
|
|
|
Web thickness:8mm
|
|
|
|
Thickness of lower wing: 12mm
|
|
|
Vehicle Quality
|
3.8T
|
|
|
Transport Items
|
Cement (density: 1200Kg / CBM)
|
|
|
Tank
|
Length: 8000mm
|
|
|
|
Minimum diameter: 1800mm
|
|
|
|
Width: 2500mm
|
|
|
|
Maximum section height: 2980mm
|
|
|
Optional
|
Single mudguard /Integrated mudguard
|
|
|
|
Ladder installation location and quantity
|
|
|
|
Intake pipe form: one pipe / two pipes / inner pipe
|
|
|
|
Tank text and color
|
|
|
Protection
|
Side / rear guard material is Q235
|
|
|
|
The lower side guard is bolted
|
|
|
|
Rear lower guard is welded
|
|
|
The rear guard has a cross-sectional height of 140mm, a width of 50mm, and a height of
460mm above the ground
|
|
|
|
|
|
|
Laser cutting machine high speed, high
precision cutting
Laser welding fixed-point welding, strong
welding force, beautiful welding seam
The suspension is automatically positioned
and welded to make it firm
The car plate and the frame are fully matched,
calibrated and positioned
Automatic welding, fast speed, beautiful
welding seam
Electrophoresis primer and powder spray coating
, the surface is smooth and flat, ensuring uniform
color in the later stage, without rust.
Ensure the accurate positioning of the tires
and avoid unnecessary problems with the tires
during transportation
The whole semi-trailer is strong and beautiful
Shandong Luen Auto Co., Ltd.
Shandong Luen Auto Co., Ltd. is a professional supplier of semi-trailers committed to improving quality and insisting on the principle of "innovation, quality, professionalism and mutual benefit" to achieve the goal of satisfying customers. Strong technical force, superb manufacturing technology, equipment and professional production team provide a solid backing quality assurance for product innovation, development and production.
