Quick Details
-
Brand Name:
-
HUNGSO
-
Model Number:
-
S-400
-
Output Frequency:
-
50/60Hz
-
Output Current:
-
3a,1.25a,0.63a
-
Size:
-
215*115*50mm
-
Weight:
-
0.91kg
-
Warranty:
-
1 Year
Quick Details
-
Input Voltage:
-
115V-230V
-
Output Voltage:
-
5v,12v,24V
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
HUNGSO
-
Model Number:
-
S-400
-
Output Frequency:
-
50/60Hz
-
Output Current:
-
3a,1.25a,0.63a
-
Size:
-
215*115*50mm
-
Weight:
-
0.91kg
-
Warranty:
-
1 Year
Product Description
Product parameters
|
Model
|
Model&Specification
|
S-400-12
|
S-400-15
|
S-400-24
|
S-400-36
|
|||
|
Output
|
DC voltage
|
12v
|
15v
|
24v
|
36v
|
|||
|
|
Rated voltage
|
33A
|
27A
|
16.7A
|
11A
|
|||
|
|
Current range
|
0-33A
|
0-27A
|
0-16.7A
|
0-11A
|
|||
|
|
Rated power
|
400w
|
400w
|
400w
|
400w
|
|||
|
|
Wave and noise(Note:3)
|
150mVp-p
|
150mVp-p
|
150mVp-p
|
150mVp-p
|
|||
|
|
Voltage adjusting range
|
10.2-13.8v
|
13.5-17v
|
22.5-26v
|
33.3-38.6v
|
|||
|
|
Voltage accuracy
|
± 3.0%
|
±1.5%
|
±1.0%
|
±1.0%
|
|||
|
|
Rate of linear adjustment
|
±0.5%
|
±0.5%
|
±0.5%
|
±0.5%
|
|||
|
|
Load adjustment rate
|
±2.0%
|
±1%
|
±0.5%
|
±0.5%
|
|||
|
Input
|
Voltage range
|
90-264VAC
|
|
|
|
|||
|
|
Frequency range
|
47-63Hz
|
|
|
|
|||
|
|
Efficiency
|
85%
|
86%
|
87%
|
90%
|
|||
|
|
Alternating current
|
3.2A/115VAC 1.6A/230vAC
|
|
|
|
|||
|
Protection
|
Excess load
|
110-140% of rated output power
|
|
|
|
|||
|
|
Overvoltage
|
13.8-15.2v
|
17-20v
|
26.5-29.7v
|
38.6-42.2v
|
|||
|
|
Working
temperature
|
-25~+70℃
|
|
|
|
|||
|
|
Working humidity
|
20-90%RH, No cooling
|
|
|
|
|||
|
|
Storage temperature and humidity
|
-40~+85℃，10-95%RH
|
|
|
|
|||
|
|
temperature coefficient
|
±0.03%/℃（0-50℃）
|
|
|
|
|||
|
Safety
|
Safety norms
|
Comply with EAC TP TC 004 BSMI CNS14336-1
|
|
|
|
|||
|
|
Withstand voltage
|
I/P-O/P:1500VAC I/P-FG:1500VAC O/P-FG:500VAC
|
|
|
|
|||
|
|
insulation resistance
|
I/P-O/P, I/P-FG,O/P-FG:100M ohms/500vdc/-25/70℃ RH
|
|
|
|
|||
|
|
Electromagnetic compatible emission
|
Comply with BSMI CNS13438,DAC TP TC 020
|
|
|
|
|||
|
|
Electromagnetic compatibility immunity
|
Comply with EAC TP TC 020
|
|
|
|
|||
|
|
MTBF
|
327.9k hrs,MIL-HDBK-217F(25℃）
|
|
|
|
|||
|
|
Size
|
215*115*50mm(L*W*H)
|
|
|
|
|||
|
|
Weight
|
0.91kg
|
|
|
|
|||
