Quick Details
-
Brand Name:
-
Shengda
-
Model Number:
-
1.588mm-50.8mm
-
Grade:
-
G16-G1000
-
Size:
-
1.588mm-50.8mm
-
Hardness:
-
HRC61-66
-
Application:
-
chemical and medical industry,sprayer
-
Package:
-
Plastic Bag+carton Box
-
Surface:
-
High Polished
-
Name:
-
stainless steel ball
-
Feature:
-
Corrosion Resistance
-
Certifications:
-
ISO9001:2008
Quick Details
-
Applicable Industries:
-
Other
-
Material:
-
Stainless steel
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Shengda
-
Model Number:
-
1.588mm-50.8mm
-
Grade:
-
G16-G1000
-
Size:
-
1.588mm-50.8mm
-
Hardness:
-
HRC61-66
-
Application:
-
chemical and medical industry,sprayer
-
Package:
-
Plastic Bag+carton Box
-
Surface:
-
High Polished
-
Name:
-
stainless steel ball
-
Feature:
-
Corrosion Resistance
-
Certifications:
-
ISO9001:2008
1. Grade: G10-G1000
2. Size: 1/16-2''
3. Standard: GB
4. Certification: ISO9001, TS16949 ISO14001
Main products
Chrome Steel Ball
| Materials |
AISI52100(GCr15, SUJ-2, 100Cr6)
|
| Diameter Range | 2mm--25.4mm |
| Precision Grade | ISO3290/G10 G16 G24 G40 G60 G100 G200 G500 G1000 |
| Hardness | HRC61-66 |
| Applications | bearing, ball screw, linear motion guide, automotive parts and so on |
Carbon Steel Ball
| Materials | AISI1010/1015 Steel |
| Diameter Range | 2mm--25.4mm |
| Precision Grade | ISO3290/G40 G60 G100 G200 G500 G1000 G2000 |
| Hardness | HRC58-62 |
| Application | drawers, rolling bearings, bicycle components and so on |
Stainless Steel Ball
| Materials | AISI201/304/316/420/440 |
| Diameter Range | 2mm--25.4mm |
| Precision Grade | ISO3290/G100 G200 G500 G1000 |
| Hardness | HRC25-39 |
| Application | chemical industry, plastic hardware, valve, nail polish, automotive fittings,... |
Composition of Different Materials
| Material | Chemical Composition(%) | ||||||||
| C | Si | Mn | P | S | Ni | Cr | Mo | Cu | |
| AISI440C | 0.95-1.20 | 1.00max | 1.00max | 0.040max | 0.030max | 0.60max | 16.00-18.00 | 0.75max | --- |
| AISI420C | 0.42-0.50 | 1.00max | 1.00max | 0.040max | 0.030max | 1.00max | 12.5-14.5 | --- | 0.30max |
| AISI304 | 0.08max | 1.00max | 2.00max | 0.045max | 0.030max | 8.00-10.50 | 18.00-20.00 | --- | --- |
| AISI316 | 0.08max | 1.00max | 2.00max | 0.045max | 0.030max | 10.00-14.00 | 16.00-18.00 | 2.00-3.00 | --- |
1.Packing Details :
In anti-oxidant paper or oiled paper , By sea or air worthy .
1) 25kg/per export carton and 40-50 cartons in one pallet
2) 10kg/box then 40 boxes in wooden case packing
3) 250kg/per steel barrel and 4 steel ball barrel in one pallet
4) Other special packing according to client's requirement
2.Delivery Details :20-30 days after receive your prepayment.
3.QINGDAO PORT
