- Product Details
- {{item.text}}
Quick Details
-
Warranty:
-
25 months, 25 Years
-
Brand Name:
-
ZHUOWEI
-
Model Number:
-
ZW530-550W
-
Place of Origin:
-
China
-
Panel Dimensions:
-
2279*1134*35mm(89.7*44.6*1.4in), 2279*1134*35mm(89.7*44.6*1.4in)
-
Product name:
-
Sola Panel
-
Weight:
-
32.7kg
-
Glass:
-
3.2mm High light transmittance, coated tempered glass
-
Connector:
-
MC4 Compatible Connector
-
OEM Order:
-
Acceptable
-
Backsheet:
-
Aging resistant film
-
Application:
-
Solar Power System
Quick Details
-
Cell size:
-
182mmx182mm
-
Type:
-
PERC, Half Cell
-
Panel Efficiency:
-
21.48%, 550W
-
Warranty:
-
25 months, 25 Years
-
Brand Name:
-
ZHUOWEI
-
Model Number:
-
ZW530-550W
-
Place of Origin:
-
China
-
Panel Dimensions:
-
2279*1134*35mm(89.7*44.6*1.4in), 2279*1134*35mm(89.7*44.6*1.4in)
-
Product name:
-
Sola Panel
-
Weight:
-
32.7kg
-
Glass:
-
3.2mm High light transmittance, coated tempered glass
-
Connector:
-
MC4 Compatible Connector
-
OEM Order:
-
Acceptable
-
Backsheet:
-
Aging resistant film
-
Application:
-
Solar Power System
Products Description
Product Parameters
Electrical Data (STC)
|
Maximum Power (Pmax/W)
|
535
|
540
|
545
|
550
|
555
|
|||||
|
Open Circuit Voltage (Voc/V)
|
49.38
|
49.53
|
49.68
|
49.83
|
49.98
|
|||||
|
Short Circuit Current (Isc/A)
|
13.54
|
13.63
|
13.71
|
13.80
|
13.88
|
|||||
|
Voltage at Maximum Power (Vmp/V)
|
40.88
|
41.03
|
41.18
|
41.31
|
41.43
|
|||||
|
Current at Maximum Power (Imp/A)
|
13.10
|
13.17
|
13.24
|
13.32
|
13.40
|
|||||
|
Module Efficiency (%)
|
20.71
|
20.90
|
21.10
|
21.29
|
21.48
|
|||||
|
Operating Temperature
|
-40° C~+85° C
|
6000 cycles
|
6000 cycles
|
6000 cycles
|
|
|||||
|
Maximum System Voltage
|
1000/1500V
|
≤20mΩ
|
≤20mΩ
|
≤20mΩ
|
|
|||||
|
STC (Standard Testing Conditions): lrradiance 1000W/m2 , Cell Temperature 25℃ , AM1.5
|
14.6±0.2V
|
14.6±0.2V
|
29.2±0.2V
|
29.2±0.2V
|
|
|||||
Temperature Coefficients
|
Temperature Coefficient (Pm)
|
-0.340%/℃
|
|
Temperature Coefficient (Voc)
|
-0.270%/℃
|
|
Temperature Coefficient (Isc)
|
0.048%/℃
|
|
NMOT (Nominal Moudule Operating Temperature)
|
41±3℃
|
Certificate
Company Introduction
Henan Zhuowei New Energy Technology Co., Ltd.
is a manufacturing factory that integrates design, research and development, production, and sales, focusing on producing new energy products for over 20 years. Its wall mounted lithium batteries, solar panels, stacked lithium batteries, bracket lithium batteries, forklift lithium batteries and other products have been sold to 65 countries and regions including the United States, Germany, Czech Republic, Netherlands, Philippines, Malaysia, Japan, Brazil, Dominican Republic, Colombia, South Africa, Kenya, Tanzania, etc.
Packing &Transport
FAQ
Q1. Can I have a sample order?
A. Yes, we welcome sample order to test and check quality.
Q2. What about the lead time?
A. Samples neeeds 10-15 days, mass production time needs 5-7 weeks, it depends on order quantity.
Q3. Do you have any MOQ limit?
A. Yes. 1~10pcs sample order is available. Low MOQ, 1pc for sample checking is available.
Q4. How do you ship the goods and how long does it take to arrive?
A. It usually takes 5-7 days to arrive. Airline and sea shipping is also optional.
Q5. How to proceed with an order?
A.
A. Yes, we welcome sample order to test and check quality.
Q2. What about the lead time?
A. Samples neeeds 10-15 days, mass production time needs 5-7 weeks, it depends on order quantity.
Q3. Do you have any MOQ limit?
A. Yes. 1~10pcs sample order is available. Low MOQ, 1pc for sample checking is available.
Q4. How do you ship the goods and how long does it take to arrive?
A. It usually takes 5-7 days to arrive. Airline and sea shipping is also optional.
Q5. How to proceed with an order?
A.
1-Identify your needs requirements.
2-We will provide you with a quotation.
3-you confirms the samples and places a deposit for formal order.
4- We arrange the production.
Q6. Is it OK to print my logo on the product?
A. Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q7. How about warranty?
A. 2 years warranty.
2-We will provide you with a quotation.
3-you confirms the samples and places a deposit for formal order.
4- We arrange the production.
Q6. Is it OK to print my logo on the product?
A. Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q7. How about warranty?
A. 2 years warranty.
