Quick Details
-
Brand Name:
-
LDOPTIC
-
Model Number:
-
WR60, WR60G
Quick Details
-
Warranty:
-
3 years
-
Power:
-
Battery
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
LDOPTIC
-
Model Number:
-
WR60, WR60G
Specification
|
item
|
value
|
|
Warranty
|
No Warrany
|
|
Customized support
|
OEM, ODM
|
|
Place of Origin
|
China
|
|
Brand Name
|
LDOPTIC
|
|
Model Number
|
WR60, WR60G
|
|
Power
|
Battery
|
Measurement Range: 0-200Gu
Application:
Apply on paint, ink, stoving varnish, coating, wood products;
Marble, granite, vitrified polished tile, pottery brick
and porcelain;Plastic, paper; Other nonmetallic material
Instrument Dimensions: 122x34x60mm
Projection Angle: 60°
Measuring Spot: (ellipse: long axis*minor axis)8mm*4mm
Measuring Mode:
Automatic measurement/ manual measurement/single measurement/average
measurement and cross measurement for a variety of combination measuring mode
Data Storage: 100 groups
Set standard sample in any stored data, user-define the tolerance range
Language: Chinese/English
Output: Connect the micro printer to realize real-time output of measured data
Division Value: 0.1Gu
Repeatability: 0.2Gu
Reproducibility: 0.4Gu
Indication Error: 1.0Gu
International Standard 60°
ISO-2813,ASTM-C584,ASTM-D523,DIN-67530,
ASTM-D2457,JND-A60,JND-P60
National Standard 60°: GB 9754,GB 9966,GB 8807
Standard Accessories: Power adapter/user manual/warranty certification/standard board
Application:
Apply on paint, ink, stoving varnish, coating, wood products;
Marble, granite, vitrified polished tile, pottery brick
and porcelain;Plastic, paper; Other nonmetallic material
Instrument Dimensions: 122x34x60mm
Projection Angle: 60°
Measuring Spot: (ellipse: long axis*minor axis)8mm*4mm
Measuring Mode:
Automatic measurement/ manual measurement/single measurement/average
measurement and cross measurement for a variety of combination measuring mode
Data Storage: 100 groups
Set standard sample in any stored data, user-define the tolerance range
Language: Chinese/English
Output: Connect the micro printer to realize real-time output of measured data
Division Value: 0.1Gu
Repeatability: 0.2Gu
Reproducibility: 0.4Gu
Indication Error: 1.0Gu
International Standard 60°
ISO-2813,ASTM-C584,ASTM-D523,DIN-67530,
ASTM-D2457,JND-A60,JND-P60
National Standard 60°: GB 9754,GB 9966,GB 8807
Standard Accessories: Power adapter/user manual/warranty certification/standard board
