Quick Details
-
Warranty:
-
1 years
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
LOMOSEN
-
Model Number:
-
ZX-SF7528C
-
Focal length:
-
75mm
-
FNO:
-
F2.8-22
-
Perspective:
-
5.4°*4.0°
-
Nearest working distance:
-
500mm
-
TV distortion:
-
<0.05%
-
Suitable chip:
-
1/1.8"
-
Filter aperture:
-
M30.5*P0.5
-
MOQ:
-
1
-
Product name:
-
ZX-SF7528C
Quick Details
-
Use:
-
Optical
-
Structure:
-
Plano-convex
-
Shape:
-
cylindrical
-
Warranty:
-
1 years
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
LOMOSEN
-
Model Number:
-
ZX-SF7528C
-
Focal length:
-
75mm
-
FNO:
-
F2.8-22
-
Perspective:
-
5.4°*4.0°
-
Nearest working distance:
-
500mm
-
TV distortion:
-
<0.05%
-
Suitable chip:
-
1/1.8"
-
Filter aperture:
-
M30.5*P0.5
-
MOQ:
-
1
-
Product name:
-
ZX-SF7528C
Product Features
Only need 1=Contact us
Highstandard design and stable quality：
Using high standard optical performance technology to achieve high product quality
High resolution： High-resolution optical design, compatible with mainstream 5MP industrial cameras, suitable for 5-megapixel
cameras with 1/1.8" chip. The resolution of the full field of view can reach 140lp/mm, ensuring the clarity of the image
High uniformity： By controlling the weakening of the edge light, using a wide-angle lens, it is also possible to achieve an overall, bright and fresh image
Low distortion： The overall distortion rate is less than 0.5%, and the minimum distortion can reach 0.03%
100% new Original. The warehouse has stock, need the friend, please contact us.
Products Description
Specifications
|
Model
|
|
ZX-SF7528C
|
|
|
|||
|
Image Size
|
|
1/1.8"
|
1/2.5"
|
1/3"
|
|||
|
Angle FOV
|
H
|
5.4°
|
4.4°
|
3.66°
|
|||
|
|
V
|
4.04°
|
3.3°
|
2.75°
|
|||
|
|
D
|
5.84°
|
5.4°
|
4.6°
|
|||
|
Focal Length
|
|
f=75mm
|
|
|
|||
|
F/NO
|
|
F=2.8-22
|
|
|
|||
|
Focus Distancr（min）
|
|
0.5m
|
|
|
|||
|
Flange Back
|
|
17.526mm in air
|
|
|
|||
|
Back Focus
|
|
42.2-55.5mm in air
|
|
|
|||
|
Distortion（TV）
|
|
<0.05%
|
|
|
|||
|
Siter Screw Size
|
|
None
|
|
|
|||
|
Mount
|
|
C-Mount
|
|
|
|||
|
Temperature Range
|
|
-10°C~50°C
|
|
|
|||
|
Visual Field Data
|
|
|
|
|||
|
Working Distance
|
Optical Magnification
|
1/1.8" Field of View（mm）
|
|
|||
|
mm
|
-
|
H
|
V
|
|||
|
6000
|
0.013x
|
553.8
|
407.7
|
|||
|
5000
|
0.015x
|
480
|
353.3
|
|||
|
4000
|
0.019x
|
378.9
|
278.9
|
|||
|
3000
|
0.026x
|
276.9
|
203.8
|
|||
|
2000
|
0.039x
|
184.6
|
135.6
|
|||
|
1500
|
0.053x
|
135.8
|
100
|
|||
|
1000
|
0.081x
|
88.9
|
65.4
|
|||
|
950
|
0.086x
|
83.7
|
61.6
|
|||
|
900
|
0.091x
|
79.1
|
58.2
|
|||
|
850
|
0.097x
|
74.2
|
54.6
|
|||
|
800
|
0.104x
|
69.2
|
51
|
|||
|
750
|
0.112x
|
64.3
|
47.3
|
|||
|
700
|
0.121x
|
59.5
|
43.8
|
|||
|
650
|
0.131x
|
55
|
40.5
|
|||
|
600
|
0.144x
|
50
|
36.5
|
|||
|
550
|
0.159x
|
45.3
|
33.3
|
|||
|
500
|
0.178x
|
44.4
|
29.8
|
|||
Product packaging
