Independent drainage system includes the gutters on the roof and seepage hole in bottom wall panel groove. Four columns are
equipped with rainwater pipes and corner fittings' outfall. The water-falling mode is upgraded from free-falling water to column
organized drainage. Meanwhile, the water seepage hole in the wall panel groove can effectively avoid rainwater infiltrating from
the bottom.
- Product Details
- {{item.text}}
Quick Details
-
Material:
-
Galvanized Steel
-
Size:
-
5800mmX2400mmX2896mm
-
Packing Size:
-
5800mmX2400mmX600mm
-
Advantage:
-
Fireproof/No rain leakage
-
Window:
-
Plastic Steel Window
-
Door:
-
Security Door
-
Wall:
-
Rcok Wool Sandwich Panel
-
Roof:
-
Light Weigt Eps Cement Panel
-
Purlin:
-
Galvanized Steel(Q235)
-
Project Solution Capability:
-
graphic design, 3D model design, total solution for projects
-
Product Type:
-
Container Houses
-
Model Number:
-
CH-Standard01
Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
HUAHUI
-
Product name:
-
Flat Pack Container House
-
Material:
-
Galvanized Steel
-
Size:
-
5800mmX2400mmX2896mm
-
Packing Size:
-
5800mmX2400mmX600mm
-
Advantage:
-
Fireproof/No rain leakage
-
Window:
-
Plastic Steel Window
-
Door:
-
Security Door
-
Wall:
-
Rcok Wool Sandwich Panel
-
Roof:
-
Light Weigt Eps Cement Panel
-
Purlin:
-
Galvanized Steel(Q235)
-
Project Solution Capability:
-
graphic design, 3D model design, total solution for projects
-
Product Type:
-
Container Houses
-
Model Number:
-
CH-Standard01
Products Description
We mainly produce Prefab House, Modular Container House and Integrated House with
strict drainage system, 100% guarantee
no leakage of rain.
♥1. The housing is easy to transport, especially the modular packaging saves transportation costs.
♥2. Durable, all made of steel, with a strong anti-seismic, anti-deformation ability
♥3. The sealing performance is good, the manufacturing process is strict, so that the product has good water resistance.
♥4. The activity room is based on a standard steel chassis, which can lead to a lot of space combinations and u p to 5 stories high . Such as conference rooms, dorms, kitchens, bathrooms and so on.
♥2. Durable, all made of steel, with a strong anti-seismic, anti-deformation ability
♥3. The sealing performance is good, the manufacturing process is strict, so that the product has good water resistance.
♥4. The activity room is based on a standard steel chassis, which can lead to a lot of space combinations and u p to 5 stories high . Such as conference rooms, dorms, kitchens, bathrooms and so on.
|
Overall Size
|
Size:5600*2200*2896mm/5800*2400*2896mm
|
|
|
|
|||
|
Main Frame
|
2.0/2.3/2.5/3.0/3.5mm thickness, with Powder Coating
|
|
|
|
|||
|
Drainage System
|
φ50mm, PVC drainage tube
|
|
|
|
|||
|
Ceilling
|
0.35/0.4mm thickness, 831 ceiling tiles with 38 angle aluminum
|
|
|
|
|||
|
Flooring
|
15/18mm fiber cement board+1.0/1.6/2.0mm PVC floor covering
|
|
|
|
|||
|
Interior Description
|
Inner corner post cover+PVC baseboard
|
|
|
|
|||
|
Door
|
size:925*1970mm/840*2035mm
|
|
|
|
|||
|
Window
|
size:925/1150*1100mm with single or double glass 3.0mm thickness
|
|
|
|
|||
|
Wall Panel
|
Width:950/1150mm, Thick:50/75mm sandwich panel with 50kgs rock wool
|
|
|
|
|||
|
Electricity System
|
Copper wire+Switch+LED Light+Distribution Box+Breaker+Socket and box
|
|
|
|
|||
|
Insulation
|
75/100mm glass wool
|
|
|
|
|||
|
Strengthening Bottom
|
Galvanized steel square tube can be add to 14 pieces
|
|
|
|
|||
|
Resistance
|
Wind resistance:Grade-11; Earthquake resistance:Grade-8
|
|
|
|
|||
|
Other
|
Fitting+995 structural silicone sealant+fastening
|
|
|
|
|||
Quality Control
Drainage System
