Quick Details
-
Application:
-
all
-
Design Style:
-
Traditional
-
Floor Heating Valve:
-
all
-
Material:
-
SBR rubber, SBR rubber
-
Place of Origin:
-
Anhui, China
-
Brand Name:
-
Jiahong
-
Model Number:
-
RS Mat-1
-
Product name:
-
Anti freezing heating rubber mat walkways stairs snow melt
-
Voltage:
-
120V/230V
-
Output:
-
200W-300W
-
Surface working temp.:
-
≤70℃
-
Mat size:
-
600mm*1000mm
-
Mat thickness:
-
9mm±1mm
-
Snow mat rate:
-
1.5-2.5" per hour
-
Cold lead:
-
H07RN-F 3G1.5sq.mm,18AWG
-
Approvals:
-
CE
Quick Details
-
Warranty:
-
2 years
-
After-sale Service:
-
Online technical support, Return and Replacement
-
Project Solution Capability:
-
graphic design, 3D model design, total solution for projects, Cross Categories Consolidation
-
Application:
-
all
-
Design Style:
-
Traditional
-
Floor Heating Valve:
-
all
-
Material:
-
SBR rubber, SBR rubber
-
Place of Origin:
-
Anhui, China
-
Brand Name:
-
Jiahong
-
Model Number:
-
RS Mat-1
-
Product name:
-
Anti freezing heating rubber mat walkways stairs snow melt
-
Voltage:
-
120V/230V
-
Output:
-
200W-300W
-
Surface working temp.:
-
≤70℃
-
Mat size:
-
600mm*1000mm
-
Mat thickness:
-
9mm±1mm
-
Snow mat rate:
-
1.5-2.5" per hour
-
Cold lead:
-
H07RN-F 3G1.5sq.mm,18AWG
-
Approvals:
-
CE
Product Description
Features
The heated snow melting mat allows you to melt away snow automatically at a rate of 2” per hour to create a safe and dry walkways and stairs. The pattern on mat not only supply a unique desirable look but also creates tread to prevent people from slipping.
- * Eliminate snow & ice accumulation
- * Portable
- * Safe and clean
- * Flexible installation
- * Durability
- * 2-year limited warranty
Technical Parameters
|
Voltage
|
230 V/120V
|
|
Output
|
200 W - 300 W
|
|
Material
|
SBR rubber
|
|
Mat size
|
23"*40" (600mm*1000mm)
|
|
Mat thickness
|
9mm±1mm
|
|
Snow melt rate
|
1.5-2.5" per hour
|
|
Surface working temp
|
≤70℃（Specific temperature changes with working environment）
|
|
Protection rating
|
IP rating:IP68
|
|
Cold lead
|
H07RN-F 3G1.5mm²，18AWG
|
Order Information
|
Model
|
Size
|
Volt
|
Watts
|
Amps
|
Weight
|
|
RS Mat 1
|
23*40
|
120 V
|
258.36 W
|
2.15 A
|
15.5 lb
|
|
RS Mat 2
|
23*40
|
120 V
|
226.04 W
|
1.88 A
|
15.5 lb
|
|
RS Mat 3
|
23*40
|
120 V
|
200 W
|
1.67 A
|
15.5 lb
|
|
RS Mat 4
|
23*40
|
120 V
|
300 W
|
2.5 A
|
15.5 lb
|
|
RS Mat 5
|
23*40
|
120 V
|
270 W
|
2.25 A
|
15.5 lb
|
|
RS Mat 6
|
23*40
|
230 V
|
324 W
|
1.4 A
|
15.5 lb
|
Approvals
Application
Portable
No need high-cost installations, mainly desighed for outdoor snow melting. It's easy to place a snow mat on the existing entranceways, stairs, loading docks, rooftops, handicap ramps and many other existing surfaces, which can provide a safe and clean passageway.
Safe
The snow melting rubber mats supply a great protection from slipping, extra traction with patterned surface is especially well for those old people and people in wheelchair. The snow melting mats will continuously melt the snow and ice to keep mat surface clean and safe.
Clean
The snow melting rubber mats definitely be the better alternative than calcium chloride, the mats won't hurt and mess your floor when people get in your house. Avoid repeat work as the mats are designed to be left outside for whole cold winter.
Durability
The snow melting rubber mats are made of SBR rubber with an electrically heating elements, these premium mats are strong enough to withstand the weight of peoples and carry enough weight and tread to prevent them from moving around in slippery environments. The pattern on mat not only supply a unique desirable look but also creates tread to prevent people from slipping. The mats should be plugged directly into standard 230V outlet with their own equipment leakage circuit interrupter.
Packing ways
We accept customer's specific packing and ODM service.
About Us
WuHu Jiahong New Material Co., Ltd
Jiahong is the largest manufacturer in Asia-pacific. We are always dedicated to research, develop and produce both constant wattage and self-regulating heating cables since 2002. Jiahong has been obtained more than 30 national patents in heating cable industry. Our products are widely used in residential, commercial and industrial areas. The main applications are indoor floor heating, roof & gutter snow melting, residential pipe freeze protection, hazardous industrial oil & gas pipe heat tracing.
Jiahong is the largest manufacturer in Asia-pacific. We are always dedicated to research, develop and produce both constant wattage and self-regulating heating cables since 2002. Jiahong has been obtained more than 30 national patents in heating cable industry. Our products are widely used in residential, commercial and industrial areas. The main applications are indoor floor heating, roof & gutter snow melting, residential pipe freeze protection, hazardous industrial oil & gas pipe heat tracing.
Most of WuHu Jiahong products passed UL, CSA, ETL, TUV, CE, ATEX etc. We export to many regions, especially North America, Europe, Australia and Asia. The most professional marketing and R&D team earn good reputation in worldwide.
Exhibitions
ADIPEC Abu Dhabi International Petroleum Exhibition 2019
ADIPEC Abu Dhabi International Petroleum Exhibition 2019
AHR HVACR 2018
AHR HVACR 2018
Why Choose Us
FAQ
Q1: Are you manufactory or trading company?
A1: We are the professional manufacturer since 2002 and specialized in constant wattage heating cables, self-regulating heating cables and thermostat.
Q2: How much the transportation freight of sample?
A2: The sample freight depends on the weight, packing size and your area.
Q3: How can I get the samples?
A3: You should pay for the cost and freight of samples, while the sample cost can be refunded after you place the order.
Q4: If your heating cable is eco-friendly?
A4: Our heating cable is all in accordance with ROHS, do not contain Lead(Pb), Cadmium(Cd), Mercury(Hg), Chromium VI(Cr VI), PBBs&PBDEs.
Q5: If your heating cable are anti-flame and waterproof?
A5: Our raw material of heating cable is all anti-flame material and waterproof classification is IP67.
Q6: Can I cut the heating cable anywhere?
A6: If you can identify parallel type and constant wattage type, the parallel type can cut and connect two cables together. But constant wattage type it's not available to cut. If you are not able to identify the type, please contact us directly.
Q7: If the heating cable can use on industrial area and hazardous area?
A7: Yes, our braiding coverage rate is over 90% and in certify to IECEx and ATEX, it's applicable to the industrial area and hazardous area.
A1: We are the professional manufacturer since 2002 and specialized in constant wattage heating cables, self-regulating heating cables and thermostat.
Q2: How much the transportation freight of sample?
A2: The sample freight depends on the weight, packing size and your area.
Q3: How can I get the samples?
A3: You should pay for the cost and freight of samples, while the sample cost can be refunded after you place the order.
Q4: If your heating cable is eco-friendly?
A4: Our heating cable is all in accordance with ROHS, do not contain Lead(Pb), Cadmium(Cd), Mercury(Hg), Chromium VI(Cr VI), PBBs&PBDEs.
Q5: If your heating cable are anti-flame and waterproof?
A5: Our raw material of heating cable is all anti-flame material and waterproof classification is IP67.
Q6: Can I cut the heating cable anywhere?
A6: If you can identify parallel type and constant wattage type, the parallel type can cut and connect two cables together. But constant wattage type it's not available to cut. If you are not able to identify the type, please contact us directly.
Q7: If the heating cable can use on industrial area and hazardous area?
A7: Yes, our braiding coverage rate is over 90% and in certify to IECEx and ATEX, it's applicable to the industrial area and hazardous area.
