Quick Details
-
Model Number:
-
FKN12-12DR
-
Max. Current:
-
630A
-
Product name:
-
12kv load break switch
-
Rated Current:
-
200A/630A
-
Rated voltage:
-
12 kV
-
Warranty:
-
one year
-
Certificate:
-
ISO9001
-
Standard:
-
IEC60947
-
Mechanical life:
-
2000 times
-
Rated frequency:
-
AC 50/60Hz
-
Operation:
-
Electro/Manual Operation
-
Application:
-
Industrial Control
Quick Details
-
Max. Voltage:
-
24 kV
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Conso Electric
-
Model Number:
-
FKN12-12DR
-
Max. Current:
-
630A
-
Product name:
-
12kv load break switch
-
Rated Current:
-
200A/630A
-
Rated voltage:
-
12 kV
-
Warranty:
-
one year
-
Certificate:
-
ISO9001
-
Standard:
-
IEC60947
-
Mechanical life:
-
2000 times
-
Rated frequency:
-
AC 50/60Hz
-
Operation:
-
Electro/Manual Operation
-
Application:
-
Industrial Control
Product Description
Specification
|
No.
|
Item
|
|
unit
|
Parameters
|
|
||
|
|
|
|
|
FKN12A-12D
|
FKN12A-12RD
|
||
|
1
|
rated voltage
|
|
KV
|
12/24/35
|
|
||
|
2
|
rated frequency
|
|
Hz
|
50
|
|
||
|
3
|
rated current
|
|
A
|
630
|
125
|
||
|
4
|
rated short time power frequency voltage tolerance(1min)
|
phase to phase
|
KV
|
42
|
|
||
|
|
|
Isolated fracture
|
|
48
|
|
||
|
5
|
rated lightning impulse voltage tolerance
|
phase to phase
|
|
75
|
|
||
|
|
|
Isolated fracture
|
|
85
|
|
||
|
6
|
rated short time withstand current(thermal steadily)
|
loading switch
|
KA
|
20
|
N/A
|
||
|
|
|
earthing switch
|
|
20
|
N/A
|
||
|
7
|
rated short circuit duration (thermal steady)
|
loading switch
|
S
|
4
|
N/A
|
||
|
|
|
earthing switch
|
|
2
|
|
||
|
8
|
rated short circuit closing current(peak)
|
|
KA
|
50
|
N/A
|
||
|
9
|
|
active loading
|
KA
|
630
|
N/A
|
||
|
|
|
closed looping
|
|
630
|
N/A
|
||
|
|
|
5% active loading
|
|
31.5
|
N/A
|
||
|
|
|
cable charging
|
|
10
|
N/A
|
||
|
10
|
breaking transformer capacity in unloading
|
|
KVA
|
1250
|
|
||
|
11
|
rated short circuit closing current(peak)
|
|
KA
|
N/A
|
31.5
|
||
|
12
|
Rated transfer current
|
|
A
|
N/A
|
1200
|
||
|
13
|
Mechanical life
|
|
Times
|
2000
|
|
||
|
14
|
Impact energy output
|
|
J
|
N/A
|
1+0.5
|
||
Product packaging
