self service payment kiosk payment machine payment terminal

FOB Reference Price: Get Latest Price

≥1 Sets

US $700

≥20 Sets

US $500

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

screen size:: 17",19"

screen brand:: sumsang LG

size:: 150x45x50cm

enclosure material:: cold rolled steel plate

touch screen:: SAW or IR

Certification:: CE,ROHS

Optional parts:: barcode, thermal printer,card reader

Warranty:: One Year

Quick Details

Place of Origin:: Guangdong, China

color:: customize

enclosure thickness:: 1.5mm

screen size:: 17",19"

screen brand:: sumsang LG

size:: 150x45x50cm

enclosure material:: cold rolled steel plate

touch screen:: SAW or IR

Certification:: CE,ROHS

Optional parts:: barcode, thermal printer,card reader

Warranty:: One Year

self service payment kiosk payment machine payment terminal

Yoyo Wang

sales5(at)lxtouch.com

skype: yoyo52013141989

-------------------------------------------------------------------------------------------------------------------------------------------------------------------------

Product Description

Specification

Display size	17"19"22"26"32"37"42"47"55"60"
Model No.	serious of LX
Type	touchscreen kiosk
Touch panel	surface sound wave touchscreen,infrared touchscreen,capacitive touchscreen or 4-wire/5-wire resistance touchscreen
Material	first class electrolysis plate, cold rolled plate
Coating	metal baking varnish(5 layers) color optional
Basic software	touchscreen driver system
Operation system	microsoft windows2000/XP/Vista,windows 7,windows 8,Linux,android
Control system	integrated circuit controller
Multimedia system	steroelectronic effects,magnetic proof sound box
Cooling system	Host independent exhaust
Host computer	based on customers' requirement
Power supply	AC 100-240V 50/60Hz
Dimension	1.4m-1.6m different from models
Working environment	temperature +0°c~+40°c,relative humidity 10%~90%
Network	RJ45 network connector
Usage	selfservice,mall,supermarket,hospital etc.
Accessories	Barcode scanner,scanner,camera,thermal printer,magnetic card reader,non-contact IC/ID card reader,coin acceptor,cash acceptor,16bit/64bit keyboard,fingerprint attendance system etc.

Configulation

1:PC host(computer part)

Motherboard: H61
CPU:Intel G2030,2.8GHz
RAM: 2G DDR3 1333+ST,320G harddisk
Big power supply power rating 300W, ultimate output 400W;1 RS-232 Ports;1 LTP;4 USB Ports,1 10/100M RJ45 port;2 loudspeaker with amplifier
Integrated Net Card, Sound Card,grafic card
I n accordance with clients, we can upgrade t he configulation of the PC

2: LCD/LED Monitor

Brightness: 300lumens/m2
Contrast: 1000:1
Response Time:Rising1.3-Falling3.7;Dot pitch: 0.264 mm
Max. resolution:1280*1024

3: Touch screen

sound wave touch screen or infrared touch screen
High Transparence, high precision and durability
Resolution:4096×4096,Brightness:300cd/m2
lens transmission:90% ~92%
Orientation precision< 2mm(0.080 inch);pure tempered glass
Single-point touch Life expectancy more 50,000,000 times
antirust,anti-acid,anti-dust

4: OS system

Windows 7 trial version,all hardware driver available
Optional,windows 2000/XP/Vista,win7,win8,Linux,Android

5: Optional accessories

Priner: Thermal priner or laserprinter can print 57~80mm width paper,A4,sticker or pictures
Keyboard : metal keyboard or plastic keyboard
Scanner
Camera
Trackball mouse
Telephone

6: Others

Durable steel frame, Slim and smart design; Easy to install and operate; Moistureproof,Antirust,Anti-acid,Anti-dust,Static free, have color and LOGO upon request.

Our Services

Pre-sales services

If it is standard touchscreen kiosk, we will offer competitive price

If clients have requirement of touchscreen kiosk, our designing&sales team will provide professional advice on your respected project and will make every effort to make your project running.

Order process:

After-sales services

We have professional members to help solve any problem during operating.

Packaging & Shipping

Four layer standard packaging: bubble foam. PE boards, carton, wooden case
