Name: log core feeder
Brand: Hanvy
Original: China
Log core feeder is a necessary part of CNC spindleless veneer peeling machine.Could convey the core log automatically after log debarking.
- Product Details
- {{item.text}}
Quick Details
-
Voltage:
-
220/380v/415V or others
-
Dimension(L*W*H):
-
5250x2275x1728mm
-
Weight (KG):
-
11000 kg
-
Applicable Industries:
-
plywood industry
-
Name:
-
9ft Veneer Peeling Machine
-
Max.rotary peeling length:
-
2600mm
-
Max.rotary peeling dia.:
-
500mm
-
Peeling speed:
-
50m/min
-
Application:
-
peeling veneer
-
Color:
-
light grey or customized
-
Delivery time:
-
within 50days after deposit
-
Clipping speed:
-
frequence adjust
-
Function:
-
peeling and clipping, 2 in 1
-
Veneer capacity per shift:
-
30 cbm approx.
Quick Details
-
Place of Origin:
-
Shandong, China
-
Type:
-
veneer making machine
-
Brand Name:
-
HANVY
-
Voltage:
-
220/380v/415V or others
-
Dimension(L*W*H):
-
5250x2275x1728mm
-
Weight (KG):
-
11000 kg
-
Applicable Industries:
-
plywood industry
-
Name:
-
9ft Veneer Peeling Machine
-
Max.rotary peeling length:
-
2600mm
-
Max.rotary peeling dia.:
-
500mm
-
Peeling speed:
-
50m/min
-
Application:
-
peeling veneer
-
Color:
-
light grey or customized
-
Delivery time:
-
within 50days after deposit
-
Clipping speed:
-
frequence adjust
-
Function:
-
peeling and clipping, 2 in 1
-
Veneer capacity per shift:
-
30 cbm approx.
Product Description
Product Application - 9ft Veneer Peeling Machine
Wood Veneer Peeling Lathe HXJ1827B/5 is a main machine of veneer peeling line.Could peel the veneer after single spindle veneer peeling machine,Max.working log diameter is 500 mm,and final log core will be 40mm.
We could manufacture 4ft,6ft ,8ft PLC spindle less veneer peeling machine or customized ones.
|
SPECIFICATIONS FOR 9ft Veneer Peeling Machine
HXJ1813B/5
|
|
|
|
|||
|
Log size
|
Working diameter
|
mm
|
500
|
|||
|
|
Max.working length
|
mm
|
1300
|
|||
|
|
Veneer thickness
|
mm
|
0.5-3.0
|
|||
|
Main performance parameters
|
Final log core diameter
|
mm
|
40
|
|||
|
|
Veneer output speed
|
m/min
|
50
|
|||
|
|
Total power
|
kw
|
34.7
|
|||
|
Machine dimension and weight
|
Overall dimension
|
mm
|
4000x2275x1728 mm
|
|||
|
|
Weight
|
kg
|
9800
|
|||
|
|
|
|
|
|||
Main Features - 9ft Veneer Peeling Machine
Wood Veneer Peeling Lathe
1)4ft spindle less veneer peeling machine combined clipper and conveyor.
2) Heavy duty iron steel structure machine body.
3) High quality spare parts and electric components,such as Siemens,Hiwin etc.
4) 500 mm max.working diameter, and 50 m/min peeling speed
5)Japan Mitsubishi control system.
6)Hydraulic knife assembly
Certifications
Detailed Images
Machine Parts- 9ft Veneer Peeling Machine
Pneumatic Middle Knife-
Wood Veneer Peeling Lathe
There is a middle knife to cut the veneer into two sheets if necessary.
Such as 8*4ft veneer into 2 sheets of 4*4ft veneers
And the knife could move along the knife groove.
Gear Transmission-
Wood Veneer Peeling Lathe
Gear transmission is much better than Chain type.
Running stable and easy maintenance.
To get high quality veneers
Control System-
Wood Veneer Peeling Lathe
Japan Mistubish Control system
Peeling Knife-
Wood Veneer Peeling Lathe
Size:2750x180x16mm,High ally steel material
Hydraulic knife assembly
Motor- Wood Veneer Peeling Lathe
Servo motor CTB,Mitsubish system and hydraulic press knife.,gear box drive,
