Quick Details
-
Model Number:
-
24v 120ah
-
Place of Origin:
-
Jiangxi, China
-
Weight:
-
30kg
-
The charging ratio:
-
0.25c
-
The discharge rate:
-
1c
-
Model:
-
RD-8IFP-120
-
Battery Cell:
-
IFP200Ah-8S1P
-
Max. Charge voltage:
-
29.2±0.5V
-
Cut-off voltage:
-
20.0±0.5V
-
BMS:
-
Bluetooth,communication Optional
-
Sample:
-
Sample provided
-
Cycle life:
-
≥2500 times@100%DOD
-
Nominal Voltage:
-
25.6V
-
Size:
-
522*240*218mm
-
Certification:
-
TQT/UN38.3/MSDS/CE
Quick Details
-
Anode Material:
-
LFP
-
Application:
-
BOATS, SUBMARINES, electric vehicles, Electric Power Systems, Solar Energy Storage Systems, Uninterruptible Power Supplies
-
Brand Name:
-
herui
-
Model Number:
-
24v 120ah
-
Place of Origin:
-
Jiangxi, China
-
Weight:
-
30kg
-
The charging ratio:
-
0.25c
-
The discharge rate:
-
1c
-
Model:
-
RD-8IFP-120
-
Battery Cell:
-
IFP200Ah-8S1P
-
Max. Charge voltage:
-
29.2±0.5V
-
Cut-off voltage:
-
20.0±0.5V
-
BMS:
-
Bluetooth,communication Optional
-
Sample:
-
Sample provided
-
Cycle life:
-
≥2500 times@100%DOD
-
Nominal Voltage:
-
25.6V
-
Size:
-
522*240*218mm
-
Certification:
-
TQT/UN38.3/MSDS/CE
Product Description
|
Cells Model
|
IFP120Ah-8S1P
|
|
Standard capacity(0.5C)
|
Typical:120.0Ah
Min:120.0Ah |
|
Rated voltage
|
24.0V
|
|
Max. Charge voltage
|
≤29.2V(standard:29.2V)
|
|
Discharge Cut-off voltage
|
20.0V
|
|
Standard charge current
|
≤ 0.25C
|
|
Rated Continuous discharge current
|
120.0A
|
|
Max continuous discharge current
|
≤120.0A
|
|
Continuous working current
|
≤120.0A
|
|
Time-delay discharge current
|
120A
|
|
Max. Instantaneous discharge current
|
180A
|
|
Single cell charge protection voltage
|
3.7V±0.05
|
|
Single cell cut-off voltage
|
2.5V±0.05V
|
|
Impedance(Max, at 1000Hz.)
|
≤ 150mΩ
|
|
Battery dimension
|
MAX L522×W240×H218mm
|
|
Weight(approx)
|
30kg
|
|
Mass Ratio of Energy
|
148Wh/Kg
|
|
Interface
|
M8 screw
|
|
Operating Temperature(CC/CV)
|
Charge: 0℃~+45℃
|
|
|
Discharge: -20℃~+60℃
|
|
|
Humidity: 50%≤RH≤85%
|
|
|
Storage: 0℃-40℃(capacity 80%)
|
Products Show
Recommend Products
Applications
Our Factory
Exhibition
Packing & Shipping
FAQ
Q1: ARE YOU A MANUFACTURER OR TRADING COMPANY?
A1: We are a manufacturer in Jiangxi more than 10 years.
Q2: CAN I HAVE A SAMPLE ORDER?
A2: Yes. We support sample order for quality inspection. Customized is available.
Q3: DO YOU HAVE ANY MOQ LIMIT?
A3: We are not very strictly with MOQ, small order is accepted.
Q4: WHAT'S YOUR LEAD TIME?
A4: Usually can be delivered within 15-25 days. Large quantities need to be negotiated.
Q5: DO YOU TEST ALL YOUR GOODS BEFORE DELIVERY?
A5: Yes, we have 100% test before delivery.
Q6: HOW DO YOU SHIP THE GOODS?
A6: We usually ship by DHL UPS, Fedex for samples and large quantities should be by sea.
Q7: DO YOU SUPPLY OEM SERVICE OR PRIVATE LABEL?
A7: Yes. We can produce according to customers requirement.
