Quick Details
-
Warranty:
-
1 years
-
Place of Origin:
-
China
-
Brand Name:
-
FengMu
-
Model Number:
-
FM-C600
-
Weight:
-
410g
-
Effective Visual Distance:
-
10000M
-
Lens:
-
50mm
-
Product Type:
-
FM-C600
-
Application:
-
Night Observation
-
Display Screen:
-
OLED Display
-
Operating Temperature:
-
-30C~70C
-
FOV:
-
7.5 X5.7
-
Battery Type:
-
Replaceable 18650 Battery
-
Zoom:
-
1X/2X/4X
-
Protection Class:
-
IP54
-
Function:
-
Thermal Scope Clip
-
Frame rate:
-
50 Hz
-
Operating Voltage:
-
5V
Quick Details
-
Size:
-
208x105x62mm
-
Type:
-
Thermal Scope
-
Magnification:
-
4.5X-7X
-
Warranty:
-
1 years
-
Place of Origin:
-
China
-
Brand Name:
-
FengMu
-
Model Number:
-
FM-C600
-
Weight:
-
410g
-
Effective Visual Distance:
-
10000M
-
Lens:
-
50mm
-
Product Type:
-
FM-C600
-
Application:
-
Night Observation
-
Display Screen:
-
OLED Display
-
Operating Temperature:
-
-30C~70C
-
FOV:
-
7.5 X5.7
-
Battery Type:
-
Replaceable 18650 Battery
-
Zoom:
-
1X/2X/4X
-
Protection Class:
-
IP54
-
Function:
-
Thermal Scope Clip
-
Frame rate:
-
50 Hz
-
Operating Voltage:
-
5V
Why Choose Us
Product Paramenters
|
Model
|
FM-C600
|
|
|
||
|
Detector type
|
Amorphous silicon uncooled infrared focal plane
|
|
|
||
|
resolution
|
384x288
|
|
|
||
|
Cell size
|
17μm
|
|
|
||
|
Field of view
|
7.5°×5.6°
|
|
|
||
|
Operating bands
|
8 - 14um
|
|
|
||
|
focal length
|
50mm
|
|
|
||
|
Frame rate
|
≤50Hz
|
|
|
||
|
Focusing method
|
Motorized focusing
|
|
|
||
|
Display resolution
|
1024x768
|
|
|
||
|
Display size
|
0.39 inches
|
|
|
||
|
Display mode
|
Infrared/Shimmer/Dual Light Fusion/Picture-in-Picture
|
|
|
||
|
Electron zoom
|
1X /2X /4X
|
|
|
||
|
palette
|
Rainbow, iron red, cool, white hot, black hot
|
|
|
||
|
WIFI
|
2.4G image transmission
|
|
|
||
|
capacity
|
Built-in 16G eMMC
|
|
|
||
|
Take photos and videos
|
In the tank
|
|
|
||
|
Image/video format
|
JPG/MP4
|
|
|
||
|
Detachable rechargeable lithium battery
|
2000mAhx4 (battery model 18650)
|
|
|
||
|
Power consumption of the whole machine
|
≤6W
|
|
|
||
|
Battery life
|
≥ 6 hours
|
|
|
||
|
Operating temperature
|
-20°C to +50°C
|
|
|
||
|
Storage temperature
|
-30°C to +70°C
|
|
|
||
|
Ingress protection
|
IP54
|
|
|
||
|
Dimensions
|
193.1mmx176.8mmx99mm
|
|
|
||
|
weight
|
1.5kg (including battery)
|
|
|
||
|
NETD
|
<50mk@25℃，@f/1.0
|
|
|
||
|
Detection distance
|
C600
|
|
|
||
|
Figures are 1.7 m x 0.5 m x 0.3m
|
3333 meters
|
|
|
||
|
Vehicle 4.5 m x 2.0 m x 1.5 m
|
8823 meters
|
|
|
||
|
Distinguish distance
|
C600
|
|
|
||
|
1.7 m x0.5mx03m
|
833 meters
|
|
|
||
|
Vehicle 4.5 m x 2.0 m x 1.5 m
|
2205 meters
|
|
|
||
