Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
OEM
-
Model Number:
-
VM III-TWINS-4K
-
Input Voltage:
-
24VDC/230VAC
-
Output Voltage:
-
230VAC
-
Output Current:
-
17.4A
-
Output Frequency:
-
50HZ/60HZ
-
Size:
-
115*300*435mm
-
Certificate:
-
ISO,CE,ect.
-
Warranty:
-
2years
-
Weight:
-
9KG
Quick Details
-
Output Type:
-
Single
-
Type:
-
DC/AC Inverters
-
Inverter Efficiency:
-
98%
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
OEM
-
Model Number:
-
VM III-TWINS-4K
-
Input Voltage:
-
24VDC/230VAC
-
Output Voltage:
-
230VAC
-
Output Current:
-
17.4A
-
Output Frequency:
-
50HZ/60HZ
-
Size:
-
115*300*435mm
-
Certificate:
-
ISO,CE,ect.
-
Warranty:
-
2years
-
Weight:
-
9KG
Product Description
Specification
1.Dual outputs for smart load management
2.Maximum PV input current 27A
3.Wide PV input voltage range 60VDC~450VDC
4.Detachable LCD control module with various communications
5.Integrated WiFi interface with Mobile App
6.Supports USB On-the-Go function
7.Reserved communication port(RS-485, CAN-BUS or RS-232) for BMS
8.Battery equalization extends lifecycle
9.Battery independence
10.User-friendly LCD operation
11.Replaceable fan design
2.Maximum PV input current 27A
3.Wide PV input voltage range 60VDC~450VDC
4.Detachable LCD control module with various communications
5.Integrated WiFi interface with Mobile App
6.Supports USB On-the-Go function
7.Reserved communication port(RS-485, CAN-BUS or RS-232) for BMS
8.Battery equalization extends lifecycle
9.Battery independence
10.User-friendly LCD operation
11.Replaceable fan design
|
Technical Specifications
|
|
|
|
Model
|
VM III-TWIN-4K
|
|
|
Rated power
|
4000VA/4000W
|
|
|
INPUT
|
|
|
|
Voltage
|
230VAC
|
|
|
Selectable Voltage Range
|
170-280VAC(for personal computers)
|
|
|
|
90-280VAC(for home appliances)
|
|
|
Frequency Range
|
50Hz/60Hz( auto sensing)
|
|
|
OUTPUT
|
|
|
|
AC Voltage Regulation (Battery Mode)
|
230VAC±5%
|
|
|
Surge power
|
8000VA
|
|
|
Efficiency (Peak)
|
90%-93%
|
|
|
Transfer time
|
10 ms(for personal computers)
|
|
|
|
20 ms(for home appliances)
|
|
|
Wave form
|
pure sine wave
|
|
|
BATTERY
|
|
|
|
Battery Voltage
|
24VDC
|
|
|
Floating Charge Voltage
|
27VDC
|
|
|
Overcharge Protection
|
33VDC
|
|
|
SOLAR CHARGER &AC CHARGER
|
|
|
|
Max PV Array Open Circuit Voltage
|
500VDC
|
|
|
Max PV Array Power
|
5000W
|
|
|
MPPT Range @operating Voltage
|
60-450VDC
|
|
|
Max Solar Charge Current
|
120A
|
|
|
Max AC Charge Current
|
100A
|
|
|
Max total Charge Current
|
120A
|
|
|
PHYSICAL
|
|
|
|
Dimension, LxWxH(mm)
|
115x300x435
|
|
|
Net weight(kgs)
|
9
|
|
|
standby power consumpsion
|
2W
|
|
|
ENVIRONMENT
|
|
|
|
Humidity
|
5% to 95% Relative Humidity (non-condensing)
|
|
|
Operating Temperature
|
-10℃ to 50℃
|
|
|
Storage Temperature
|
-15℃ to 60℃
|
|
