Quick Details
-
Place of Origin:
-
China
-
Brand Name:
-
BEIYA
-
Model Number:
-
BW-500
-
Dimension(L*W*H):
-
2.1*1.4*1.8
-
Weight:
-
800kgs
-
Certification:
-
CE ISO
-
Production quantity:
-
500cartons/hour
-
Carton material:
-
gable top carton
-
Structure:
-
Linear
-
Feed cylinder structure:
-
Single room feeding
-
Material type:
-
Liquid
-
Filling type:
-
Volumetric filling machine
-
Filling valve head:
-
single head
-
Packaging container lifting structure:
-
Pneumatic lifting
-
Filling principle:
-
Atmospheric pressure
-
Guarantee:
-
One year
Quick Details
-
Packaging Material:
-
Paper
-
Voltage:
-
380V
-
Power:
-
16KW
-
Place of Origin:
-
China
-
Brand Name:
-
BEIYA
-
Model Number:
-
BW-500
-
Dimension(L*W*H):
-
2.1*1.4*1.8
-
Weight:
-
800kgs
-
Certification:
-
CE ISO
-
Production quantity:
-
500cartons/hour
-
Carton material:
-
gable top carton
-
Structure:
-
Linear
-
Feed cylinder structure:
-
Single room feeding
-
Material type:
-
Liquid
-
Filling type:
-
Volumetric filling machine
-
Filling valve head:
-
single head
-
Packaging container lifting structure:
-
Pneumatic lifting
-
Filling principle:
-
Atmospheric pressure
-
Guarantee:
-
One year
manual yogurt carton sealing machine
1. Scope of Application
Suitable for filling liquid dairy product, juice, milk, milk beverage, cream, yogurt, mineral water, soy milk, tea beverage, seasoning, wine
2. Product Display
3. Work Flow
4. Technical parameter:
|
Capacity |
500,1000ml |
|
|
Output |
500cartons/h |
|
|
Packing material |
gable top carton |
|
|
Shelf life |
depend on different product and different production process |
|
|
Capping |
optional |
|
|
Overall power |
16KW (three phases of power electricity) |
|
|
Compressed air |
Pressure: 1.0-1.4 Mpa |
Flow rate: 0.8-1.0M 3 /min |
|
Cooling water |
Flow volume: ≥20L/ min |
Temperature: normal temperature |
|
Size: (L*W*H) |
2.1*1.4*1.8m |
|
|
Net Weight |
800kg |
|
|
Installation requirement |
Any smooth floor, such as cement, floor tile, plastic ground, etc. Do not need to make angle. |
|
5. Payment terms
1)T/T : 30% as deposit , 70% balance before shipment
2) L/C
6. Deliver time
1) For automatic filling machine 60 days
2) For semi-automatic filling machine 45 days
3) For manual filling machine 30 days
7. After – sale service
Shenyang Beiya Beverage Machinery Co.,Ltd will supply 12monthes guarantee for all the equipments, and if customer need,
we will send our technicians to customer, install the machines and train customer's people to operate the machine. we will
supply all the spare parts with cost price if customer need.
8. Certificate
9. Final package
We will use standard export wooden packages, and also before packing, we will protect all the machines by pe film, avoiding the sea water come inside and pollute machines.
Welcome to our factory any time at your convenience!
No matter customer come to visit us or not, we will take care about the machines' quality and ensure all the machines with perfect quality.
If customer not visit us and inspect the machines, we will take video for the testing machines and send to our customer, let them have a whole view about our qualitiy ,then we deliver the machines.
We appreciate all the customers' trust, we will use our best service and quality to return our customer
Hope we can do good business with you!!
