- Product Details
- {{item.text}}
Quick Details
-
Size:
-
13000*3000*(700mm-1200mm)
-
Place of Origin:
-
Shandong, China
-
Product name:
-
Low Bed Semi Trailer
-
Suspension:
-
Mechanical
-
Axle:
-
3 axles
-
Landing Gear:
-
JOST / FUWA 28T
-
Axle Brand:
-
13/16 Ton Fuwa/BPW
-
King pin:
-
2"(50mm)or3.5"(90mm) JOST
-
Brake System:
-
WABCO Valve
-
Tire:
-
12R22.5
-
Color:
-
Yellow
-
Rims:
-
8.00-20 /8.5-20/8.8-20/8.5-22.5/9.0-22.5
Quick Details
-
Type:
-
Semi-Trailer
-
Max Payload:
-
80TON
-
Brand Name:
-
LUYI
-
Size:
-
13000*3000*(700mm-1200mm)
-
Place of Origin:
-
Shandong, China
-
Product name:
-
Low Bed Semi Trailer
-
Suspension:
-
Mechanical
-
Axle:
-
3 axles
-
Landing Gear:
-
JOST / FUWA 28T
-
Axle Brand:
-
13/16 Ton Fuwa/BPW
-
King pin:
-
2"(50mm)or3.5"(90mm) JOST
-
Brake System:
-
WABCO Valve
-
Tire:
-
12R22.5
-
Color:
-
Yellow
-
Rims:
-
8.00-20 /8.5-20/8.8-20/8.5-22.5/9.0-22.5
Luyi trailer 60 tons 3 axle low bed trailer dimensions 40ft low boy trailer for sale
Products Description
Lowbed Truck Semi Trailer Manufacture 3/4 Axles Lowbed Semitrailer/Lowbed Semi Trailer
We can design and manufacture lowbed semi trailer according to your exact requirements, the following specifications for your reference.
We can design and manufacture lowbed semi trailer according to your exact requirements, the following specifications for your reference.
|
Dimensions
|
13000*3000*(700mm-1200mm) (According to customer demand)
|
|
Axle specs.
|
FUWA ,YAHUA or BPW Brand
|
|
Suspension
|
Mechanical or air supension (American or German)
|
|
Rim
|
6.5-20/8.25-22.5/9.00*22.5 /80-.0-20/8.5-20
|
|
King Pin
|
JOST 2" or 3.5" traction pin
|
|
Support legs
|
JOST, FUWA or YAHUA brand 28T
|
|
Wheelbase
|
7180/6680/6260+1310+1310mm,Or other
|
|
Steel Spring
|
8/8/8, 10/10/10, 12/12/12 pieces per axle
|
|
Ladder
|
Manual or hydraulic automatic
|
|
Electrical system
|
24V, 7 pin socket, One set 7-core standard Cable
|
|
Tire
|
8.25R20/8.25R16/11.00R22.5/12.00R22.5/10.00R20/11.00R20/12.00R20
|
|
Spare Tire Carriers
|
2 pieces
|
|
The material of Main beam
|
Height: 450mm-520mm, upper plate thickness is 14mm-25mm, middle plate thickness is 8mm-12mm, down plate thickness is 16mm-25mm;
Material is Q345 Carbon Steel. |
|
Side beam
|
16mm-25mm channel steel (Material is Q235 carbon steel)
|
|
Platform plate
|
5/6/7 mm Diamond Plate
|
|
Brake
|
Kemi Brand of China
|
|
Brake Chamber
|
WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber(TAIYUE brand); One piece of 45L air tanks
|
|
ABS system
|
optional
|
|
Light
|
Tail lamp with turn signal, brake light & reflector, side lamp etc
|
|
Tool box
|
1 sets(waterproof type)
|
|
Spare tire carrier
|
1 sets(Patent type)
|
|
Painting
|
Complete Chassis sand blasting to clean rust, 2 coat of anticorrosive primer, 2 coats of final paint
|
|
Packing
|
Polish with wax before shipping |
