Quick Details
-
Working pressure:
-
14 bar
-
Motor power:
-
132kw
-
Capacity:
-
14m3/min
-
Cooling method:
-
air-cooled, water-cooled, in-line
-
Screw machine:
-
from atllas
-
Noise:
-
82±3
-
Certification:
-
ISO9001.ISO14001 OHSAS18001
-
Power brand:
-
Cummins
Quick Details
-
Place of Origin:
-
Liaoning, China
-
Brand Name:
-
Atlas Copco
-
Air capacity:
-
1378CFM
-
Working pressure:
-
14 bar
-
Motor power:
-
132kw
-
Capacity:
-
14m3/min
-
Cooling method:
-
air-cooled, water-cooled, in-line
-
Screw machine:
-
from atllas
-
Noise:
-
82±3
-
Certification:
-
ISO9001.ISO14001 OHSAS18001
-
Power brand:
-
Cummins
- The robust design guarantees longer lifetime and reliability.
Great service access
- The large service diirs give easy access to all consumables,including the filters and separator. We offer long intervals beetween servicing and reduced time to perform the service.
Complying to China III non-road machinery exhaust pollutants standard
- The fuel injection system provides higher fuel pressure, good combustion,more power,but importantly, is cleaner for the environment.
Fuel autonomy
- Thanks to the large fuel tank capacity, the compressors can run for a full work shift without the need for refueling - even under 100% full load conditions.
Low noise level
- All components are houses inside a custom designed noise-dampening canopy.
| Model:XATS156C | |||||
|
Working pressure (bar) |
Flow (m3/min) |
Noise sound level (at 7m distance, dBA) |
Fuel tank capaticy (L) |
Compressor oil capaticy (L) |
Outlet valves (qty*size) |
| 15-35 | 32.3-38.6 | 83 ± 3 | 185 | 47 |
1* 1½,1*¾
|
| Engine | |||||
| Engine maker | Engine model |
Engine power (kW) |
Norminal engine speed (rpm) |
Unloading engine speed (rpm) |
Engine inspiration |
| Caterpillar | 3B5.9-C210 | 403 | 1000 | torbue charger | |
| Dimension&Weight | |||||
| Box mounted | |||||
| Length(mm) | Width(mm) | Height(mm) | Weight(mm) | ||
| 5400 | 2250 | 2510 | 6250 | ||
-
Ground Engineering Drilling
Pneumatic rock drills,block cutters,dewatering pumps and hand-held pneumatic breakers. They are suited for stabilization projects on roads and building sites,as well as basement and foundation excavation for apartment blocks and other buildings. -
Blast Hole Drilling
Common applications include aggregate production for costruction stabilization,cement production in limestone quarries and open pit mining.
