Quick Details
-
Dimension (L*W*H):
-
30*45*50
-
Weight:
-
55kg
-
Voltage:
-
51.2V
-
Nominal Voltage:
-
51.2v
-
Material:
-
LifePo4 Lithium Iron Battery
-
Battery cell:
-
A- Grade
-
Battery type:
-
Lithium Ion
-
Protection:
-
Built-in Smart BMS
-
Payment:
-
T/T
-
BMS:
-
Built-in
-
Product name:
-
BSM48106LP
-
Shipping:
-
Sea
Quick Details
-
Model Number:
-
BSM48106LP
-
Brand Name:
-
Bluesun
-
Place of Origin:
-
Anhui, China
-
Dimension (L*W*H):
-
30*45*50
-
Weight:
-
55kg
-
Voltage:
-
51.2V
-
Nominal Voltage:
-
51.2v
-
Material:
-
LifePo4 Lithium Iron Battery
-
Battery cell:
-
A- Grade
-
Battery type:
-
Lithium Ion
-
Protection:
-
Built-in Smart BMS
-
Payment:
-
T/T
-
BMS:
-
Built-in
-
Product name:
-
BSM48106LP
-
Shipping:
-
Sea
Products Description
Product Paramenters
|
MODEL
|
BST-5.0LV
|
BST-10.0LV
|
BST-15.0LV
|
BST-20.0LV
|
BST-25.0LV
|
BST-30.0LV
|
||||||
|
Battery Type
|
LiFeP04(LFP)
|
|
|
|
|
|
||||||
|
Nominal Voltage(V)
|
51.2V
|
|
|
|
|
|
||||||
|
Nominal Capacity(KWH)
|
5.42KWH
|
10.85KWH
|
16.28KWH
|
21.7KWH
|
27.13KWH
|
32.56KWH
|
||||||
|
Usable Capacity(KWH)
|
4.87KWH
|
9.76KWH
|
14.65KWH
|
19.53KWH
|
24.41 KWH
|
29.30KWH
|
||||||
|
Design Life
|
10+Years （25 ℃/77F)
|
|
|
|
|
|
||||||
|
Physical
|
|
|
|
|
|
|
||||||
|
Dimension(mm)
|
600*400*385
|
600*400*534
|
600*400*683
|
600*400*832
|
600*400*981
|
600*400*1130
|
||||||
|
Weight (kg)
|
80
|
125
|
170
|
215
|
260
|
305
|
||||||
|
ELECTRICAL
|
|
|
|
|
|
|
||||||
|
Cycle Life
|
>6000. 25°C
|
|
|
|
|
|
||||||
|
Discharge Voltage(V)
|
40-48
|
|
|
|
|
|
||||||
|
Charge Voltage(V)
|
56 -58.4
|
|
|
|
|
|
||||||
|
Charge/Discharge Current(A)
|
83 (Recommended) 100A(Max)
|
|
|
|
|
|
||||||
|
Internal Resistance
|
≤30mΩ
|
|
|
|
|
|
||||||
|
BMS
|
|
|
|
|
|
|
||||||
|
Power Consumption
|
<2W (Work) < 100mW(Sleep)
|
|
|
|
|
|
||||||
|
Monitoring Parameters
|
System voltage, current, cell voltage,cell temperature, module temperature
|
|
|
|
|
|
||||||
|
SOC
|
Intelligent algorithm
|
|
|
|
|
|
||||||
|
Communication
|
CAN/RS-485/RS-232
|
|
|
|
|
|
||||||
|
OPERATION
|
|
|
|
|
|
|
||||||
|
Operating Temperature Range
|
-10℃-50℃
|
|
|
|
|
|
||||||
|
Transport or Storage Temperate Range
|
-20℃-45℃
|
|
|
|
|
|
||||||
|
Humidity
|
15% - 85% (No Condensing)
|
|
|
|
|
|
||||||
|
WARRANTY
|
|
|
|
|
|
|
||||||
|
Product Warranty
|
5 Years
|
|
|
|
|
|
||||||
|
Performance Warranty
|
10 Years
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|||||||
Matching Inverter
High compatibility BMS, seamless communication with energy storage inverter
