Quick Details
-
Brand Name:
-
uniview
-
Model Number:
-
UAC-T112-F28(40)
-
model 1:
-
UAC-T112-F28
-
model 2:
-
UAC-T112-F40
-
Weight:
-
205g(0.452lb)
-
Material:
-
Plastic
-
Dimensions:
-
118mm*96mm (diameter*height)
-
Ingress protection:
-
IP67
-
Product name:
-
2MP ColourHunter HD Fixed Turret Analog Camera
-
Size:
-
1/3"
-
Support:
-
TVI/AHD/CVI/CVBS
Quick Details
-
Special Features:
-
NIGHT VISION, Waterproof / Weatherproof
-
Function:
-
NIGHT VISION, Waterproof / Weatherproof, Vandal-proof, Analog Camera
-
Customized support:
-
Online technical support, Customized logo, Software reengineering, OEM, ODM
-
Brand Name:
-
uniview
-
Model Number:
-
UAC-T112-F28(40)
-
model 1:
-
UAC-T112-F28
-
model 2:
-
UAC-T112-F40
-
Weight:
-
205g(0.452lb)
-
Material:
-
Plastic
-
Dimensions:
-
118mm*96mm (diameter*height)
-
Ingress protection:
-
IP67
-
Product name:
-
2MP ColourHunter HD Fixed Turret Analog Camera
-
Size:
-
1/3"
-
Support:
-
TVI/AHD/CVI/CVBS
You may also like
Product Description
UAC-T112-F28(40)
2MP HD Fixed IR Turret Analog Camera
2MP HD Fixed IR Turret Analog Camera
• TVI/AHD/CVI/CVBS
• IR-cut filter with auto switch (ICR)
• Supports 180° horizontal flip, 180° vertical flip
• OSD configuration menu, easy to operate
• IP67 waterproof and dustproof design, high reliability
• OSD configuration menu in 11 languages
Specification
|
Model
|
UAC-T112-F28
|
UAC-T112-F40
|
||
|
Sensor
|
|
|
||
|
Pixel
|
2MP
|
|
||
|
Size
|
1/3"
|
|
||
|
Minimum illumination
|
0.02 lux (F2.0, AGC ON)
|
|
||
|
|
0 lux (IR on)
|
|
||
|
Lens
|
|
|
||
|
Lens
|
2.8mm
|
4.0mm
|
||
|
Lens mount
|
M12
|
|
||
|
Angle of view
|
H: 90.5° V: 49.6° D: 109.5°
|
H: 80.2° V: 40.7° D: 90.5°
|
||
|
Illuminator
|
|
|
||
|
Illuminator
|
One IR illuminator
|
|
||
|
Illumination distance
|
20m
|
|
||
|
Lifetime
|
≥60,000 hours
|
|
||
|
|
|
|
||
|
Resolution
|
1080P: 1920(H)×1080(V)
|
|
||
|
|
720P: 1280(H) ×720(V)
|
|
||
|
Frame rate
|
TVI/AHD/CVI: 1080P@30fps, 1080P@25fps; 720P@30fps, 720P@25fps
|
|
||
|
|
CVBS: PAL, NTSC
|
|
||
|
Shutter time
|
PAL: 1/25s-1/50000s
|
|
||
|
|
NTSC: 1/30s–1/50000s
|
|
||
|
|
|
|
||
|
Exposure mode
|
4 modes: Global (default), BLC, HLC, DWDR
|
|
||
|
Day/Night
|
3 modes: Auto (default), Day, Night
|
|
||
|
Digital noise reduction
|
2D
|
|
||
|
White balance
|
Two modes: Auto (default), Manual
|
|
||
|
WDR
|
DWDR
|
|
||
|
Smart IR
|
Support
|
|
||
|
Flip
|
Supports 180° horizontal flip, 180° vertical flip.
|
|
||
|
Interface
|
|
|
||
|
Power
|
5.5mm power interface
|
|
||
|
Video output
|
BNC, supports TVI/AHD/CVI/CVBS
|
|
||
|
Operating environment
|
|
|
||
|
Temperature
|
-30℃ to 60℃(-22℉ to 140℉)
|
|
||
|
Humidity
|
≤95% (RH, non-condensing)
|
|
||
|
Surge protection
|
4KV
|
|
||
|
Ingress protection
|
IP67
|
|
||
|
General
|
|
|
||
|
Power
|
DC 12V(±25%), with reverse polarity protection and surge protection, Max 2.88W
|
|
||
|
Mount
|
Surface mount (default), optional backbox, wall mount bracket
|
|
||
|
Dimensions
|
Φ118mm*96mm (diameter*height)
|
|
||
|
Material
|
Plastic
|
|
||
|
Weight
|
182g(0.401lb)
|
|
||
|
Certification
|
CB, CE, FCC
|
|
||
