Quick Details
-
Model Number:
-
BNP96
-
Place of Origin:
-
Shandong, China
-
Product name:
-
Nucleic Acid Extractor
-
Sample Capacity Screen:
-
10.1 inch touch
-
Sample Volume:
-
20-1000 Microliter
-
Sample Capacity:
-
1-96
-
External Size(W*D*H):
-
770*530*540mm
-
Power Supply:
-
AC1 00V-240V 50Hz/60Hz
-
Disinfection Method:
-
UV Light, Aerosol adsorption
-
Program Storage:
-
> 100 groups
-
ReagentType:
-
Open System for Magnetic Bead Method
-
Shock Mixing:
-
Adjustable Speed (1-3)
Quick Details
-
Warranty:
-
1 Year
-
After-sale Service:
-
Online technical support
-
Brand Name:
-
BIOBASE
-
Model Number:
-
BNP96
-
Place of Origin:
-
Shandong, China
-
Product name:
-
Nucleic Acid Extractor
-
Sample Capacity Screen:
-
10.1 inch touch
-
Sample Volume:
-
20-1000 Microliter
-
Sample Capacity:
-
1-96
-
External Size(W*D*H):
-
770*530*540mm
-
Power Supply:
-
AC1 00V-240V 50Hz/60Hz
-
Disinfection Method:
-
UV Light, Aerosol adsorption
-
Program Storage:
-
> 100 groups
-
ReagentType:
-
Open System for Magnetic Bead Method
-
Shock Mixing:
-
Adjustable Speed (1-3)
Product Introduction
Lab Using Auto Nucleic Acid Extraction System BNP96
The BNP96System is optimized for high-throughput nucleic acid purification – 96 samples extracted in less than one hour. Requiring minimal setup with the help of pre-filled reagent kits, preloaded protocols for a broad range of sample types, and deck surveillance, the BNP96 System maximizes productivity and dramatically reduces handling errors.
Features:
1. High purity extraction, easy to operate and fully automated.
2. High throughput, can process 1-96 samples at a time, save time.
3. With professional extraction kit, extraction process optimization.
4. Large program capacity, can store 1-100 groups of programs.
5. With constant temperature function to ensure the best reaction temperature in the purification process
6. Friendly operation interface, easy to understand, no external computer, no special training.
7. Compact appearance, solid material, long design life
2. High throughput, can process 1-96 samples at a time, save time.
3. With professional extraction kit, extraction process optimization.
4. Large program capacity, can store 1-100 groups of programs.
5. With constant temperature function to ensure the best reaction temperature in the purification process
6. Friendly operation interface, easy to understand, no external computer, no special training.
7. Compact appearance, solid material, long design life
Specification
|
Model
|
BNP96
|
|
Sample Capacity Screen
|
10.1 inch touch
|
|
Sample Volume
|
20-1000 Microliter
|
|
Sample Capacity
|
1-96
|
|
Magnetic Bead Recovery
|
> 98%
|
|
Extraction Time |
15-40 minutes |
|
Extracting the Difference Between Holes
|
CV<3%
|
|
Consumption
|
500W
|
|
Operating Temperature
|
RT - 120℃
|
|
Product Purity A260/A280
|
DNA> 1.7-2.0; RNA> 1.8-2.1
|
|
Shock Mixing
|
Adjustable Speed (1-3)
|
|
ReagentType
|
Open System for Magnetic Bead Method
|
|
Program Storage
|
> 100 groups
|
|
Safety Door Design
|
Safety door opened, the program operation will be automatically suspended, avoid cross-contamination
|
|
Disinfection Method
|
UV Light, Aerosol adsorption
|
|
Power Supply
|
AC1 00V-240V 50Hz/60Hz
|
|
External Size(W*D*H)
|
770*530*540mm
|
|
Package Size(W*D*H)
|
910*670*780mm
|
|
Gross Weight
|
95kg
|
Delivery & Packing
After-sales Service & Global Exhibition
FAQ
1.Why choose BIOBASE?
We are the leading manufactuer in lab furniture and lab equipment, OEM & ODM service are
offered. And we have our own overseas techinican and installation team.
2.How about the sample of Biobase product?
We could send you the samples but the freight and the sample are charged.
3.How about Biobase payment term?
T/T & L/C &Western Union (40%deposit, the balance before shipment)
4.How about BIOBASE delivery time?
Within 7-15 workdays after receiving deposit.
5.How about BIOBASE validity of quotation ?
Usually 30 days as the shipping freight and exchange rate can be fluctuant.
6.What is the shipping port?
FOB to Qingdao Port，China (also can ship according to customers’ request)
7.How about the package?
Bubble film + Cotton+Standard export wooden case.
8.How to inspect the goods?
Products will be checked by our QC staff frist, then our proejct manager. Client can come and check bythemselves or third party
check is available.
We are the leading manufactuer in lab furniture and lab equipment, OEM & ODM service are
offered. And we have our own overseas techinican and installation team.
2.How about the sample of Biobase product?
We could send you the samples but the freight and the sample are charged.
3.How about Biobase payment term?
T/T & L/C &Western Union (40%deposit, the balance before shipment)
4.How about BIOBASE delivery time?
Within 7-15 workdays after receiving deposit.
5.How about BIOBASE validity of quotation ?
Usually 30 days as the shipping freight and exchange rate can be fluctuant.
6.What is the shipping port?
FOB to Qingdao Port，China (also can ship according to customers’ request)
7.How about the package?
Bubble film + Cotton+Standard export wooden case.
8.How to inspect the goods?
Products will be checked by our QC staff frist, then our proejct manager. Client can come and check bythemselves or third party
check is available.
