Quick Details
-
Brand Name:
-
Top one
-
Model Number:
-
MPPT
-
Work Time (h):
-
24
-
Max PV Power:
-
7200W
-
Max PV Voltage:
-
150V
-
Certificate:
-
CE , FCC
-
Warranty:
-
1 Year, 1 Year
-
Display:
-
LCD+LED Display
-
Color:
-
Silver
-
Battery type:
-
Sealed Gel AGM Flooded Lithium
-
Charge way:
-
Sunshine
-
System voltage:
-
DC 12V/24V/48V Automatic Recognition
-
MPPT efficiency:
-
96.5%-99%
-
Protection:
-
Short Circuit
-
Charging current:
-
60 Ampere
Quick Details
-
Type:
-
MPPT
-
Application:
-
Charger Controller, Solar Working Station, Solar System Controller
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Top one
-
Model Number:
-
MPPT
-
Work Time (h):
-
24
-
Max PV Power:
-
7200W
-
Max PV Voltage:
-
150V
-
Certificate:
-
CE , FCC
-
Warranty:
-
1 Year, 1 Year
-
Display:
-
LCD+LED Display
-
Color:
-
Silver
-
Battery type:
-
Sealed Gel AGM Flooded Lithium
-
Charge way:
-
Sunshine
-
System voltage:
-
DC 12V/24V/48V Automatic Recognition
-
MPPT efficiency:
-
96.5%-99%
-
Protection:
-
Short Circuit
-
Charging current:
-
60 Ampere
|
Model
|
|
AP-20
|
AP-30
|
AP-40
|
AP-50
|
AP-60
|
AP-80
|
|||||||
|
Rated Current
|
|
20A
|
30A
|
40A
|
50A
|
60A
|
80A
|
|||||||
|
Maximum Charging
Current
|
|
22A
|
32A
|
42A
|
52A
|
62A
|
82A
|
|||||||
|
Mppt Range Operating Voltage
|
|
|
|
|
|
|
|
|||||||
|
12VDC
|
|
18VDC~80VDC
|
|
|
|
|
|
|||||||
|
24VDC
|
|
30VDC~100VDC
|
|
|
|
|
|
|||||||
|
36VDC
|
|
40VDC~100VDC
|
|
|
|
|
|
|||||||
|
48VDC
|
|
60VDC~150VDC
|
|
|
|
|
|
|||||||
|
96VDC
|
|
Not Available
|
|
|
|
120VDC~200VDC
|
|
|||||||
|
Maximum Pv Array Power
|
|
|
|
|
|
|
|
|||||||
|
12VDC
|
|
280W
|
420W
|
570W
|
700W
|
900W
|
1140W
|
|||||||
|
24VDC
|
|
550W
|
840W
|
1130W
|
1400W
|
1700W
|
2260W
|
|||||||
|
36VDC
|
|
840W
|
1260W
|
1710W
|
2100W
|
2700W
|
3420W
|
|||||||
|
48VDC
|
|
1100W
|
1650W
|
2270W
|
2800W
|
3400W
|
4540W
|
|||||||
|
96VDC
|
|
Not Available
|
|
|
|
7200W
|
9120W
|
|||||||
|
Battery
|
|
|
|
|
|
|
|
|||||||
|
Supportable Battery Type
|
|
Gel/SLA/AGM/Water/Lithium(lifepo4) battery
|
|
|
|
|
|
|||||||
|
Charging Mode
|
|
Three Stages: Constand Current(mppt),equalizing Charge, Floating Charge
|
|
|
|
|
|
|||||||
|
Maximum Efficiency
|
|
≥99%
|
|
|
|
|
|
|||||||
|
Communication Portal
|
|
|
|
|
|
|
|
|||||||
|
Communication
|
|
RS485, available for wifi box & external control screen
|
|
|
|
|
|
|||||||
|
Physical
|
|
|
|
|
|
|
|
|||||||
|
Dimension,
D*W*H(MM)
|
|
315*235*150
|
|
|
360*260*190
|
|
|
|||||||
|
G.W.(KGS)
|
|
3.5KGS
|
|
|
4.5KGS
|
|
|
|||||||
|
*Product Specifications Are Subject To Change Without Further Notice
|
|
|
|
|
|
|
|
|||||||
