Quick Details
-
Material:
-
Aluminum shell, Aluminum
-
Brand Name:
-
YUCOO
-
Model Number:
-
YK-CD1218
-
output voltage and current:
-
48V/6A, 48V/10A, 48V/15A, 134.4V/7A, 71.4V/15A, 84V/15A, 24V/15A, 48V/30A
-
Maximum Output Power:
-
300W, 600W, 800W, 1000W, 1071W, 1260W, 360W, 1800W
-
Place of Origin:
-
Guangdong, China
-
Product name:
-
battery charger
-
Application:
-
Car battery charger
-
Use for:
-
Electric Motorcycle
-
Power:
-
120-300W
-
Plug:
-
Customers' Requirements
-
Battery type:
-
Lifepo4/lithium /Lead Acid Battery
-
Dimension:
-
172.3*90.6*51~303*158*92mm
-
Weight:
-
1.1~3.5KG
-
Warranty:
-
1 Year
Quick Details
-
Type:
-
Electric
-
Port:
-
AC
-
Usage:
-
battery charger
-
Material:
-
Aluminum shell, Aluminum
-
Brand Name:
-
YUCOO
-
Model Number:
-
YK-CD1218
-
output voltage and current:
-
48V/6A, 48V/10A, 48V/15A, 134.4V/7A, 71.4V/15A, 84V/15A, 24V/15A, 48V/30A
-
Maximum Output Power:
-
300W, 600W, 800W, 1000W, 1071W, 1260W, 360W, 1800W
-
Place of Origin:
-
Guangdong, China
-
Product name:
-
battery charger
-
Application:
-
Car battery charger
-
Use for:
-
Electric Motorcycle
-
Power:
-
120-300W
-
Plug:
-
Customers' Requirements
-
Battery type:
-
Lifepo4/lithium /Lead Acid Battery
-
Dimension:
-
172.3*90.6*51~303*158*92mm
-
Weight:
-
1.1~3.5KG
-
Warranty:
-
1 Year
Y
ou need to communicate your needs and place an order in advance, and then you can better buy your own suitable products.
Hot Sale
Features:
1. AC input: AC: 90-264v/200-240v (Pull switch), 45~65Hz/50HZ 2. Output power:300W/450W/600W/800W/1000W/1260W/1071W 3. DC output voltage: 48V/6A, 24V/15A,48V/10A, 48V/15A, 134.4V/7A,84V/15A,71.4V/15A 4. LED indicator light logo: red and green, double color instructions, red charging green finished or standby 5. Efficiency: >90% 6. MTBF: 30000 hours 7. Main export markets: Asia/Eastern Europe/Mid East/Africa/Australasia/North America/Central/South America/Western Europe
1. AC input: AC: 90-264v/200-240v (Pull switch), 45~65Hz/50HZ 2. Output power:300W/450W/600W/800W/1000W/1260W/1071W 3. DC output voltage: 48V/6A, 24V/15A,48V/10A, 48V/15A, 134.4V/7A,84V/15A,71.4V/15A 4. LED indicator light logo: red and green, double color instructions, red charging green finished or standby 5. Efficiency: >90% 6. MTBF: 30000 hours 7. Main export markets: Asia/Eastern Europe/Mid East/Africa/Australasia/North America/Central/South America/Western Europe
Specification
|
Model
|
YK-CD30
|
YK-CD70
|
YK-CD80
|
YK-CD120
|
YK-CD1500
|
YK-CD600M
|
YK-CD2500
|
|||||||
|
AC input
|
90~265V
|
90~264V
|
90~264V
|
90~264V
|
200~240V
|
90~264V
|
90~264V
|
|||||||
|
Frequency
|
45~65HZ
|
45~65HZ
|
45~65HZ
|
45~65HZ
|
50HZ
|
45~65HZ
|
45~65HZ
|
|||||||
|
Voltage
|
48V
|
48V
|
48V
|
134.4V
|
84V/71.4V
|
24V
|
48V
|
|||||||
|
Current
|
6A
|
10A
|
15A
|
7A
|
15A
|
15A
|
30A
|
|||||||
|
Power
|
300W
|
600W
|
800W
|
1000W
|
1260W/1071W
|
360W
|
1800W
|
|||||||
|
Size
|
172.3*90.6*51mm
|
200*90*63mm
|
222.4*120.2*70.2mm
|
267.4*160*10.8mm
|
267.5*155.8*95.5mm
|
197*89*63mm
|
303*158*92mm
|
|||||||
|
Weight
|
1.1Kg
|
1.3Kg
|
2.5Kg
|
3.0Kg
|
3.0Kg
|
1.5Kg
|
3.5Kg
|
|||||||
|
Operating temperature
|
-20~40℃
|
-20~40℃
|
-20~40℃
|
-20~40℃
|
-25~40℃
|
-20~40℃
|
-20~40℃
|
|||||||
|
Protections
|
Short circuit/over voltage/over current/reverse polarity/over temperature
|
|
|
|
|
|
|
|||||||
|
Features
|
|
|
|
|
Embedded microcontroller intelligent control,Optional OLED display,With fan design, cooling by
fan |
Fanless design, natural cooling.Fully enclosed aluminum case, IP65
|
Embedded microcontroller intelligent control,Built-in active PFC(PFC>0.9@220VAC),With fan design, cooling by fan
|
|||||||
|
|
|
|
|
|
|
|
||||||||
