1/2.8" 4Megapixel CMOS.
· 5x optical zoom.
· Max. 25/30fps@4MP.
· IR distance up to 50m.
· Warm light illumination distance up to 30 m.
· Built-in Mic and Speaker for Two-way Talk.
· Perimeter protection.
· SMD 3.0.
· Wi-Fi.
· IP66.
- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Original brand
-
Model Number:
-
SD3C405DB-GNY-AW-PV
-
Video Compression Format:
-
265, H--265+
-
Smart Dual Light:
-
Outdoor
-
WizSense Wi-Fi Network:
-
distance up to 30 m
-
Management Software:
-
DMSS; DSS Pro
-
Perimeter protection:
-
SMD 3.0.
-
Power Supply:
-
12 VDC
Quick Details
-
Special Features:
-
NIGHT VISION, Face Recognition, Vandal-proof, Human Motion Tracking, Face detection, Motion Detection, Waterproof / Weatherproof, People Counting, Two-way Audio, Temperature Measurement, Sound Detection
-
Function:
-
Waterproof / Weatherproof, Two-way Audio, Vandal-proof, PAN-TILT, NIGHT VISION, Built-in Mic, Alarm I/O
-
Customized support:
-
Online technical support, Customized logo, OEM, ODM
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Original brand
-
Model Number:
-
SD3C405DB-GNY-AW-PV
-
Video Compression Format:
-
265, H--265+
-
Smart Dual Light:
-
Outdoor
-
WizSense Wi-Fi Network:
-
distance up to 30 m
-
Management Software:
-
DMSS; DSS Pro
-
Perimeter protection:
-
SMD 3.0.
-
Power Supply:
-
12 VDC
Recommend Products
Products Description
SD3C405DB-GNY-AW-PV
|
Image Sensor
|
1/2.8" CMOS
|
|
Pixel
|
4 MP
|
|
Max. Resolution
|
2560 (H) × 1440 (V)
|
|
ROM
|
128 MB
|
|
RAM
|
512 MB
|
|
Electronic Shutter Speed
|
1/1 s–1/30,000 s
|
|
Scanning System
|
Progressive
|
|
Min. Illumination
|
Color: 0.005 lux@F1.6
B/W: 0.0005 lux@F1.6 0 lux (IR light on) |
|
Illumination Distance
|
50 m (164.04 ft) (IR);30 m (98.43 ft) (Warm light)
|
|
Illuminator On/Off Control
|
Zoom Prio; Manual; Auto; Off
|
|
Illuminator Number
|
2 (IR); 2 (Warm light)
|
|
Lens
|
|
|
Focal Length
|
2.7 mm–13.5 mm
|
|
Max. Aperture
|
F1.6–F3.0
|
|
Field of View
|
H: 94.9°–30.1°;
V: 51°–17.1°; D: 112.3°–34.6° |
|
Optical Zoom
|
5 ×
|
|
Focus Control
|
Auto; semi-auto; manual
|
|
Close Focus Distance
|
1.5 m (4.92 ft)
|
|
Iris Control
|
Fixed
|
|
DORI Distance
|
Detect
|
|
|
270 m
(885.83 ft) |
|
|
*DORI (Detect, Observe, Recognize, Identify) is a standard
system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/ project design tool. |
|
PTZ
|
|
|
Pan/Tilt Range
|
Pan: 0° to 355°
Tilt: –15° to +90° |
|
Manual Control Speed
|
Pan: 0.1°/s–36°/s
Tilt: 0.1°/s–25.8°/s |
|
Preset Speed
|
Pan: 35.7°/s; Tilt: 27.1°/s
|
|
Preset
|
300
|
|
Power-off Memory
|
Yes
|
|
Idle Motion
|
Preset
|
|
Intelligence
|
|
|
IVS (Perimeter Protection)
|
Tripwire; intrusion; crossing fence detection; loitering
detection; abandoned/missing object; fast moving; parking detection; people gathering; vehicle/human alarm classification |
|
SMD
|
Yes
|
|
| DH-SD3C405DB-GNY-AW-PV
|
|
|
Interoperability
|
ONVIF (Profile S & Profile G & Profile T);CGI;SDK;P2P
|
|
Streaming Method
|
Unicast/Multicast
|
|
User/Host
|
20 (total bandwidth: 64 M)
|
|
Storage
|
FTP/SFTP; Micro SD card (512 GB); NAS
|
|
Browser
|
IE 9 and later versions
Chrome 41 and later versions Firefox 50 and later versions Safari 10 and later versions |
|
Management Software
|
DMSS; DSS Pro
|
|
Mobile Client
|
iOS; Android
|
|
Certification
|
|
|
Certifications
|
CE: EN55032/EN55024/EN50130-4
|
|
Port
|
|
|
Audio Input
|
1 channel (built-in mic)
|
|
Audio Output
|
1 channel (built-in speaker)
|
|
Alarm Linkage
|
Capture; recording; send email; preset; audio; warning
light |
|
Alarm Event
|
Motion/tampering detection; audio detection;
network disconnection detection; IP conflict detection; memory card state detection; memory space detection |
|
Power
|
|
|
Power Supply
|
12 VDC, 1.5 A ± 25%
|
|
Power Consumption
|
Basic: 3 W
Max: 11 W (illuminator + PTZ + speaker) |
|
Environment
|
|
|
Operating Temperature
|
–30 °C to +60 °C (–22 °F to +140 °F)
|
|
Operating Humidity
|
≤95%
|
|
Protection
|
IP66; TVS 2000 V lightning proof; surge protection;
voltage transient protection |
|
Structure
|
|
|
Product Dimensions
|
142.6 mm × 140.0 mm × 236.2 mm (5.61" × 5.51" ×
9.30") (L × W × H) |
|
Net Weight
|
1.1 kg (2.43 lb)
|
|
Gross Weight
|
1.7 kg (3.75 lb)
|
