Quick Details
-
Output Speed:
-
1.3~193rpm
-
Place of Origin:
-
China
-
Brand Name:
-
ep
-
Model Number:
-
WJ30~WJ150
-
Rated Power:
-
0.09~7.5kw
-
Ratio:
-
7.5~100
-
Color:
-
RAL9006 aluminium, RAL5010 blue or other
-
Input Form:
-
IEC flange, solid shaft
-
Output Form:
-
Solid shaft, hollow shaft
-
Mounting Position:
-
Foot mounted, flange mounted or torque arm mounted
-
Certificate for motor:
-
CE,UL,CSA
-
Material:
-
Cast aluminium alloy, Cast iron
-
Quality Control System:
-
ISO9001:2008
Quick Details
-
Gearing Arrangement:
-
Worm
-
Output Torque:
-
up to 880Nm
-
Input Speed:
-
<2000rpm
-
Output Speed:
-
1.3~193rpm
-
Place of Origin:
-
China
-
Brand Name:
-
ep
-
Model Number:
-
WJ30~WJ150
-
Rated Power:
-
0.09~7.5kw
-
Ratio:
-
7.5~100
-
Color:
-
RAL9006 aluminium, RAL5010 blue or other
-
Input Form:
-
IEC flange, solid shaft
-
Output Form:
-
Solid shaft, hollow shaft
-
Mounting Position:
-
Foot mounted, flange mounted or torque arm mounted
-
Certificate for motor:
-
CE,UL,CSA
-
Material:
-
Cast aluminium alloy, Cast iron
-
Quality Control System:
-
ISO9001:2008
small worm gearboxes for lift
Small size: standard export packing (carton and pallet);
Big size: fumigated wood carton or non-wood packing material carton
About us
We are one of the leading manufacturers of worm gearbox in China, specialized in gearbox industry for 22 years. Our products have been reputed by our customers for long. Manufacturing according to the ISO9001 quality control system guidelines. We help our customer develop special gearbox for their application and OEM service offered.
Product features
1. WJ series worm reducer gear box adopt aluminium alloy or cast iron square housing, small size and elegant appearance.
2. It is flexible and convenient to install,steady running,efficent radiator,low noise,high carrying ability.
3. The products have been widely used for machinery equipment, such as chemical, plating, ceramic, pharmaceutical, leather, foods,beverage,etc.
General Technical data
| Housing material | ZL108 Al-alloy or HT200 cast iron |
| Worm wheel material | ZCuSn10Pb1 |
| Worm gear material | 40Cr |
| Lubricating oil | GB Gn230-460 Synthetic or Mineral oil |
| Efficiency | 50%~65% |
| Noise (MAX) | 60~68dB |
| Temp. rise (MAX) | 50 °C |
| Temp. rise (Oil)(MAX) | 60 °C |
| Vibration | ≤ 20µm |
| Backlash | ≤ 20Arcmin |
| Brand of bearings | C&U or other brand requested |
| Brand of oil seal | NAK --- Taiwan or other brands requested |
| Model | Shaft Dia. | (mm) | Center Height | Output Flange Dia. | Power | Ratio | Permitted torque | Weight |
| Solid(h6) | Hollow(h7) | (mm) | (mm) | (kw) | (Nm) | (KGS) | ||
| Wj30 | 14 | 14 | 40 | 80 | 0.09~0.3 | 7.5~100 | 22 | 1.5 |
| Wj40 | 19 | 18/19 | 50 | 110 | 0.12~0.5 | 7.5~100 | 55 | 2.5 |
| Wj50 | 25 | 25 | 60 | 125 | 0.18~0.7 | 7.5~100 | 120 | 4 |
| Wj63 | 25 | 25 | 72 | 180 | 0.37~1.5 | 7.5~100 | 175 | 6 |
| Wj75 | 28 | 28 | 86 | 200 | 0.55~3 | 7.5~100 | 280 | 9 |
| Wj90 | 35 | 35 | 103 | 210 | 0.75~4 | 7.5~100 | 425 | 13.5 |
| Wj110 | 42 | 42 | 127.5 | 270 | 1.1~5.5 | 7.5~100 | 585 | 43 |
| Wj130 | 45 | 45 | 147.5 | 320 | 1.5~7.5 | 7.5~100 | 850 | 67 |
| Wj150 | 50 | 50 | 170 | 320 | 2.2~15 | 7.5~100 | 1500 | 100 |
| Remark: the weight without motor | ||||||||
