Quick Details
-
Power:
-
8KW
-
Dimension(L*W*H):
-
User Requirements
-
Weight:
-
5-7T
-
Machinery Capacity:
-
100L Per Batch
-
Name:
-
Mini Beer Factory 100L 100Liter Electric Beer Mash Tun Brew Kettle
-
Capacity:
-
100L
-
Material:
-
SUS304/SUS316/Red Copper
-
Keywords:
-
Homebrew equipment
-
Heating way:
-
Electronic/Steam Heating
-
Control system:
-
Manual/Semi-automated
-
Application:
-
Home Brewing/Pilot Brewing
-
Color:
-
Silver/Red copper
-
Optional:
-
Chiller;Malt miller
-
After Warranty Service:
-
Video technical support, Online support, Field maintenance and repair service
-
Local Service Location:
-
Canada, United Kingdom, United States, Italy, France, Germany, Russia, Australia
-
After-sales Service Provided:
-
Video technical support
-
Certification:
-
CE ISO
Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
TONSEN
-
Voltage:
-
220V/380V/Customization
-
Power:
-
8KW
-
Dimension(L*W*H):
-
User Requirements
-
Weight:
-
5-7T
-
Machinery Capacity:
-
100L Per Batch
-
Name:
-
Mini Beer Factory 100L 100Liter Electric Beer Mash Tun Brew Kettle
-
Capacity:
-
100L
-
Material:
-
SUS304/SUS316/Red Copper
-
Keywords:
-
Homebrew equipment
-
Heating way:
-
Electronic/Steam Heating
-
Control system:
-
Manual/Semi-automated
-
Application:
-
Home Brewing/Pilot Brewing
-
Color:
-
Silver/Red copper
-
Optional:
-
Chiller;Malt miller
-
After Warranty Service:
-
Video technical support, Online support, Field maintenance and repair service
-
Local Service Location:
-
Canada, United Kingdom, United States, Italy, France, Germany, Russia, Australia
-
After-sales Service Provided:
-
Video technical support
-
Certification:
-
CE ISO
Mini Beer Factory 100L 100Liter Electric Beer Mash Tun Brew Kettle
Description
|
Brewhouse Type
|
Single Vessel/2 Vessel/ 3 Vessel/4 Vessel
|
|
Heating way:
|
Steam heating / Electric heating / Direct fire heating
|
|
Material:
|
SUS 304,SUS 316,Red copper outshell
|
|
Spare Parts
|
25% head space;
Full sanitary butterfly valves; Equip with Electromagnetic valve; 360°coverage CIP spraying ball; Tube level with measurements;
False bottom/ sieve plate for lauter tun;
Raker with VFD for mash/lauter
Tangential port for whirlpool
Sparge ring for lauter tun;
Thermowell with high accuracy temperature sensor: PT100
Ice water pipe: PPR; Ice water pipe insulation: Rock-Wool; Stainless steel manway(option:glass manway)
Option:led lamp
Other special request, can be customized according for your brewhouse
|
|
Manufacture Arts
|
100% TIG welding with pure argon gas shield;
Interior Finish: Overall polishing to ≤0.6μm without dead corner Inner tank inside surface fully acid washed and passivated after polishing;form protective film, easy to clean, no sanitary dead angle. |
|
Beer Fermenter
|
|
|
|
Material:
|
SUS 304, SUS 316,Fish scale stainless steel
|
|
|
Thickness:
|
Interior Shell: 3mm/4mm, can be customized
Exterior Shell: 2mm/3mm, can be customized |
|
|
Insulation:
|
Polyurethane-thickness: 80-100mm
|
|
|
Cooling jacket:
|
Dimpled plate jackets on cone and side
|
|
|
Cooling media
|
Glycol water
|
|
|
Spare Parts
|
25% head space;
Full sanitary sample valve; Equip with Electromagnetic valve; Shockproof pressure gauge on CIP arm; Water sealed spunding valve; Safety valve on fermenter top; Tri-clamp discharge arm with butterfly valve; Dry hopping port with hops adding device; CIP arm with 360°coverage CIP spraying ball; Thermowell with high accuracy temperature sensor: PT100 Ice water pipe: PPR; Ice water pipe insulation: Rock-Wool; Carbonation device for CO2 is option; Tapper angle 60°(~90°) |
|
|
Manufacture Arts
|
100% TIG welding with pure argon gas shield;
Interior Finish: Overall polishing to ≤0.6μm without dead corner Inner tank inside surface fully acid washed and passivated after polishing;form protective film, easy to clean, no sanitary dead angle. |
|
Note
:1.1Hectolitre(HL)=100Liter; 1Barrel(BBL)=117Liter
2.Water supply: water supply, for mashing, cooling, cleaning
3. Electricity supply: 3-phase electricity
4. Voltage/frequency adjust to your local power supply
5.Material: malted barley or wheat, hops, water
