Quick Details
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Jinle
-
Model Number:
-
ZD1973BF
-
Torque:
-
10N.m
-
Operation Mode:
-
S2
-
Voltage:
-
12v
-
Power:
-
3kw
-
Speed:
-
3000rpm
-
Rotation:
-
CCW
-
O.D:
-
127MM
-
specification:
-
electric 12 volt motor for lifting equipment
Quick Details
-
Speed(RPM):
-
3000RPM
-
Continuous Current(A):
-
120A
-
Efficiency:
-
Other
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Jinle
-
Model Number:
-
ZD1973BF
-
Torque:
-
10N.m
-
Operation Mode:
-
S2
-
Voltage:
-
12v
-
Power:
-
3kw
-
Speed:
-
3000rpm
-
Rotation:
-
CCW
-
O.D:
-
127MM
-
specification:
-
electric 12 volt motor for lifting equipment
electric 12 volt motor for lifting equipment
Features :
1.low noise,stable running
2.easy brush replacement
3.OEM service available electric 12 volt motor for lifting equipment
4.efficient and long continuous running time
5. Customization available
6.robust construction for long and reliable service life
7.100% copper wire electric 12 volt motor for lifting equipment
8.12V, 24V, 36V, 48V,60V,72V as per customers' option
9.Factory established in 1996 with nearly 20 years' manufacturing experience
1.Specification of electric 12 volt motor for lifting equipment :
| type | voltage | power | Speed | Rotation | O.D |
| ZD2973BF | 24V | 3KW | 3000rpm | CCW | 127MM |
| ZD1973BF | 12V | 3KW | 3000rpm | CCW | 127MM |
Work duty : S2
Insulation class: H
Protection class: Ip54
Price:We have our own factory so that we can offer the more competitive price
Quality:Topest materials,skilled workers and strict test system to provide good quality products
Usage:The products are widely used in electric folk-lift truck, electric rail car, electric sightseeing car and so on
2.Drawings of electric 12 volt motor for lifting equipment
3.Parameters:
| Unload | Speed(n) | 3954(rpm) |
| Current(l) | 106.520(A) | |
| Max_Torque | Torque(M) | 6.860(N.m) |
| Current(I) | 274.810(A) | |
| Speed(n) | 2070(RPM) | |
| Eff | 44.72% | |
| Output Power(P2) | 1487.30(W) | |
| Max_Efficiency: | Eff | 57.66% |
| Speed(n) | 2642(RPM) | |
| Torque(M) | 4.970(N.m) | |
| Current(I) | 201.230(A) | |
| Output Power(P2) | 1374.40(W) | |
| Max_Pout: | Eff | 44.72% |
| Speed(n) | 2070(RPM) | |
| Torque(M) | 6.860(N.m) | |
| Current(I) | 274.810(A) | |
| Output Power(P2) | 1487.30(W) |
Q: Do you accept OEM manufacturing?
A: Yes! We do accept OEM manufacturing. You could give us your samples or drawings.
electric 12 volt motor for lifting equipment
Q: Can we design our own package or print our own logo?
A: Yes! You could! Package will be acording to your requirements?
electric 12 volt motor for lifting equipment
Q: Could we get the samples?
A: Yes! Definitly! The samples will be sent to you.
