Quick Details
-
Weight:
-
25000 kg
-
Materials for spreading:
-
Snow Melting Agents
-
Power:
-
210hp
-
Customized support:
-
Yes
-
Working width:
-
3 meters
-
Snow melt spreader:
-
2-15 meters
-
Snow melt tank volume:
-
6000 liters
-
Spreading disc diameter:
-
500 mm
-
Chassis:
-
optional
-
Color:
-
optional
-
Equipment:
-
Snow shovel (3meters length), 4 units sweep plate
Quick Details
-
Place of Origin:
-
Hubei, China
-
Brand Name:
-
Dongfeng
-
Dimension(L*W*H):
-
9830*2490*3190
-
Weight:
-
25000 kg
-
Materials for spreading:
-
Snow Melting Agents
-
Power:
-
210hp
-
Customized support:
-
Yes
-
Working width:
-
3 meters
-
Snow melt spreader:
-
2-15 meters
-
Snow melt tank volume:
-
6000 liters
-
Spreading disc diameter:
-
500 mm
-
Chassis:
-
optional
-
Color:
-
optional
-
Equipment:
-
Snow shovel (3meters length), 4 units sweep plate
|
Item |
unit |
parameter |
||
|
Truck Model |
|
SCS5250TCX |
||
|
Driving model |
|
Left hand drive |
||
|
Cab color |
|
optional |
||
|
Water tank color |
|
optional |
||
|
Overall dimensions |
mm |
9830 *2490*3 190 |
||
|
GVW |
kg |
25000 |
||
|
Curb Weight |
|
12600 |
||
|
Payload |
|
1 2205 |
||
|
Wheel base |
mm |
4350+1300 |
||
|
Exhaust/hp |
ml/ps |
5900/210 |
||
|
Max speed |
km/h |
80 |
||
|
Tire specification |
10.00 R 20 |
Engine type |
B210 33 |
|
|
|
|
|
|
|
|
Traction system |
6*4 |
Transmission |
8 -speed with over drive |
|
|
|
|
|
|
|
|
Number of axles |
3 |
Axle Load(kg) |
5 000 / 100 00 |
|
|
|
|
|
|
|
|
Engine |
Cummins,diesel, 6 -cylinder in-line with super charge inner cooling |
|||
|
Emission standard |
Euro 3 |
|||
|
Tank |
Material |
Carbon steel |
||
|
|
Thickness |
4mm |
||
|
|
Water tank v olume |
7 000 L |
||
|
Snow melt spreader
|
Snow melt tank volume |
6000L |
||
|
|
Spreader material |
carbon steel 4mm |
||
|
|
Engine: |
Working pressure of diesel hydraulic system: ≥16MPa |
||
|
|
Feed form: |
scraper |
||
|
|
Spreading width: |
2-15m |
||
|
|
Salt sprinkling amount: |
20-300g/m2(adjustable) |
||
|
|
Spreading disc diameter: |
500mm |
||
|
Equipment |
Snow shovel (3meters length), 4 units sweep plate |
|||
|
Equipment |
Cabin |
Heater, Flat head,two door, with a sleeper |
||
|
|
Apartment |
1 |
||
|
|
Manhole |
1 |
||
|
|
water pump |
1 |
||
|
|
Arrows lamp |
2 |
||
|
|
sprinkling equipment both in front and in rear; with water pump |
|||
|
Producing time |
Within 20 days |
|||
