Quick Details
-
Productivity:
-
120 M3/H
-
Place of Origin:
-
Hunan, China
-
Brand Name:
-
Zoomlion
-
Weight:
-
45300 kg
-
Model:
-
36X-5Z
-
Maximum theorical output:
-
120/80 m3/h
-
Maximum pressure on concrete:
-
70/110 bar
-
Conc. cylinders (diam. x stroke):
-
130*2100 mm
-
Concrete hopper capacity:
-
550 L
-
Maximum vertical reach:
-
35.5 m
-
Maximum horizontal distance:
-
35.15 m
-
Minimum unfolding height:
-
8.5 m
-
Section numbers:
-
5
-
End hose lenght:
-
3 m
Quick Details
-
Power Type:
-
Diesel
-
Max. vertical conveying distance:
-
35.5 M
-
Max. horizontal conveying distance:
-
35.15 M
-
Productivity:
-
120 M3/H
-
Place of Origin:
-
Hunan, China
-
Brand Name:
-
Zoomlion
-
Weight:
-
45300 kg
-
Model:
-
36X-5Z
-
Maximum theorical output:
-
120/80 m3/h
-
Maximum pressure on concrete:
-
70/110 bar
-
Conc. cylinders (diam. x stroke):
-
130*2100 mm
-
Concrete hopper capacity:
-
550 L
-
Maximum vertical reach:
-
35.5 m
-
Maximum horizontal distance:
-
35.15 m
-
Minimum unfolding height:
-
8.5 m
-
Section numbers:
-
5
-
End hose lenght:
-
3 m
Product Description
Specification
|
Model
|
|
Unit
|
36X-5Z
|
|
|
Pump Unit
|
Maximum theorical output
|
m3/h
|
120/80
|
|
|
|
Maximum pressure on concrete
|
bar
|
70/110
|
|
|
|
Conc. cylinders (diam. x stroke)
|
mm
|
130*2100
|
|
|
|
Concrete hopper capacity
|
L
|
550
|
|
|
|
Hydraulic circuit
|
|
Open
|
|
|
Boom Section
|
Maximum vertical reach
|
m
|
35.5
|
|
|
|
Maximum horizontal distance
|
m
|
35.15
|
|
|
|
Minimum unfolding height
|
m
|
8.5
|
|
|
|
Section numbers
|
|
5
|
|
|
|
Rotating angle
|
|
±270°
|
|
|
|
End hose lenght
|
m
|
3
|
|
