Quick Details
-
Output Speed:
-
0.18-206 rpm
-
Warranty:
-
1 year
-
Weight (KG):
-
80 KG
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Guomao
-
Product name:
-
Cycloidal Reducer
-
Type:
-
BWD/BLD Cycloidal Gearbox
-
Color:
-
Customer Request
-
Heat treatment:
-
Carburising/quenching/gear grinding
-
Housing Material:
-
HT200
-
Gear Hardness:
-
HRC58-62
-
Gear material:
-
low carbon high alloy steel
-
Mounting Position:
-
Horizontal (foot Mounted), Vertical
-
Certification:
-
CCC,CQM,Supplier Assessment
-
Quality:
-
Super
Quick Details
-
Gearing Arrangement:
-
Cycloidal
-
Output Torque:
-
up to 30 kNm
-
Input Speed:
-
750-3000 rpm
-
Output Speed:
-
0.18-206 rpm
-
Warranty:
-
1 year
-
Weight (KG):
-
80 KG
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Guomao
-
Product name:
-
Cycloidal Reducer
-
Type:
-
BWD/BLD Cycloidal Gearbox
-
Color:
-
Customer Request
-
Heat treatment:
-
Carburising/quenching/gear grinding
-
Housing Material:
-
HT200
-
Gear Hardness:
-
HRC58-62
-
Gear material:
-
low carbon high alloy steel
-
Mounting Position:
-
Horizontal (foot Mounted), Vertical
-
Certification:
-
CCC,CQM,Supplier Assessment
-
Quality:
-
Super
Products Description
Product Specification
|
No
|
Item
|
Data
|
|
1
|
Product Name
|
Cycloidal gear speed reducer
|
|
2
|
Model
|
BW, BWD, BWED, BWSD, etc.
|
|
3
|
Weight
|
80KGS
|
|
4
|
Output torque
|
up to 30kNm
|
|
5
|
Input speed
|
750-3000 rpm
|
|
6
|
Output speed
|
0.18-206 rpm
|
|
7
|
Housing material
|
HT200 cast iron
|
|
8
|
Gear material
|
20CrMnTi alloy steel
|
|
9
|
Ambient temperature
|
-10℃ to 40℃
|
|
10
|
Moisture
|
under 85%
|
|
11
|
Altitude
|
blow 1000 meter
|
|
12
|
Air environment
|
no corrosive, explosive air, good circulation of air
|
|
13
|
Heat treatment
|
Quenching/Carburising/Gear Grinding
|
|
14
|
Certificate
|
CCC, CQM, Supplier Assessment,MA
|
Product packaging
