Quick Details
-
Warranty:
-
25 Years Warranty, 25 Years
-
Brand Name:
-
Longi, Longi Solar
-
Model Number:
-
Hi-MO 6
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
2094*1038*35mm
-
Application:
-
Solar Power System
-
Certificate:
-
TUV, TUV/CE/ETL/CEC/ISO
-
Solar cell:
-
A-grade
-
Keyword:
-
Pv Module
-
Frame:
-
Anodized Aluminium Alloy
-
Junction Box:
-
IP68 Rated
-
Weight:
-
23.5kg
-
Connector:
-
MC4 Compatible Connector
Quick Details
-
Cell size:
-
182*91mm
-
Type:
-
PERC, Half Cell, Bifacial, Double-glass, All Black, HJT, N-TYPE, TOPCON, Flexible
-
Panel Efficiency:
-
20.23
-
Warranty:
-
25 Years Warranty, 25 Years
-
Brand Name:
-
Longi, Longi Solar
-
Model Number:
-
Hi-MO 6
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
2094*1038*35mm
-
Application:
-
Solar Power System
-
Certificate:
-
TUV, TUV/CE/ETL/CEC/ISO
-
Solar cell:
-
A-grade
-
Keyword:
-
Pv Module
-
Frame:
-
Anodized Aluminium Alloy
-
Junction Box:
-
IP68 Rated
-
Weight:
-
23.5kg
-
Connector:
-
MC4 Compatible Connector
|
Electrical Characteristics
|
|
|
|
|
||||
|
Model Number
|
LR4-72HPH-445M
|
LR4-72HPH-450M
|
LR4-72HPH-455M
|
LR4-72HPH-460M
|
||||
|
Maximum Power (Pmax/W)
|
445
|
450
|
455
|
460
|
||||
|
Open Circuit Voltage
|
49.1
|
49.3
|
49.5
|
49.7
|
||||
|
Short Circuit Current (Isc/A)
|
11.53
|
11.60
|
11.66
|
11.73
|
||||
|
Voltage at Maximum Power (Vmp/V)
|
41.3
|
41.5
|
41.7
|
41.9
|
||||
|
Current at Maximum Power (Imp/A)
|
10.78
|
10.85
|
10.92
|
10.98
|
||||
|
Module Efficiency (%)
|
20.5
|
20.7
|
20.9
|
21.2
|
||||
|
STC (Standard Testing Conditions): Irradiance 1000W/m2, Cell Temperature 25 ℃， Spectra at AM1.5
|
|
|
|
|
||||
