Quick Details
-
Size:
-
6200x2990x785
-
Place of Origin:
-
Shandong, China
-
Tyre:
-
215/75R17.5
-
Rim:
-
6.0x17.5
-
Suspension:
-
Hydraulic suspension with tri-point support
-
Certification:
-
ISO,CCC
Quick Details
-
Type:
-
Semi-Trailer
-
Max Payload:
-
22500kg/lines
-
Brand Name:
-
Aotong Brand
-
Size:
-
6200x2990x785
-
Place of Origin:
-
Shandong, China
-
Tyre:
-
215/75R17.5
-
Rim:
-
6.0x17.5
-
Suspension:
-
Hydraulic suspension with tri-point support
-
Certification:
-
ISO,CCC
4 Lines Steering Axle Modular Trailers
| Basic Data | Manufactory | Juyuan Trailer |
| Platform Size (mm) | 6200x2990 | |
| Min Height (mm) | 785 | |
| Floating Height (mm) | 600 | |
| Rated capacity (Tons) | 22500kg/lines | |
| Suspension | Axle No. | 8 |
| Tire Size | 32pcs 215/75R 17.5 Michelin tire | |
| Rims | 6.0x17.5 | |
| Wheel base (mm) | 1550 | |
| Brake System | Dual line pneumatic brake system | |
| suspension | Hydraulic suspension with tri-point support | |
| Hydraulic working pressure | 250 bar | |
| Main Beam |
Material
|
WH60, Q345C
|
A typical SPMT has a grid of computer-controlled axles, usually 2 axles across and 4-8 axles along. When two (or more) axles are placed side-by-side, this is called an axle line. All axles are individually controllable, in order to evenly distribute weight and steer accurately. Each axle can swivel through 360°. The axles are coordinated by the control system to allow the SPMT to turn, move sideways or even spin in place. Some SPMTs allow the axles to telescope independently of each other so that the load can be kept flat and evenly distributed while moving over uneven terrain. Each axle can also contain a hydrostatic drive unit.
SPMT
are used in many industry sectors worldwide such as the construction and oil industries, in the shipyard and offshore industry, for road transportation, on plant construction sites and even for moving oil platforms. Recently in addition, they have begun to be used to replace bridge spans in the United States, Europe, Asia and more recently Canada.
