Customized Ku Band  LNB Strong Signal Satellite KU Band Dsih Receiver  10.7-12.75GZH  lnb for Project area
Customized Ku Band  LNB Strong Signal Satellite KU Band Dsih Receiver  10.7-12.75GZH  lnb for Project area
Customized Ku Band  LNB Strong Signal Satellite KU Band Dsih Receiver  10.7-12.75GZH  lnb for Project area
Customized Ku Band  LNB Strong Signal Satellite KU Band Dsih Receiver  10.7-12.75GZH  lnb for Project area
Customized Ku Band  LNB Strong Signal Satellite KU Band Dsih Receiver  10.7-12.75GZH  lnb for Project area
Customized Ku Band  LNB Strong Signal Satellite KU Band Dsih Receiver  10.7-12.75GZH  lnb for Project area
Customized Ku Band  LNB Strong Signal Satellite KU Band Dsih Receiver  10.7-12.75GZH  lnb for Project area
Customized Ku Band  LNB Strong Signal Satellite KU Band Dsih Receiver  10.7-12.75GZH  lnb for Project area

Customized Ku Band LNB Strong Signal Satellite KU Band Dsih Receiver 10.7-12.75GZH lnb for Project area

FOB Reference Price: Get Latest Price
≥2 Pieces
US $85
≥500 Pieces
US $75
Free Inquiry
Customized Request
  • Product Details
  • {{item.text}}

Quick Details

Input frequency::
10.7-12.75GZH
Output frequency::
950-2150mhz
L.O Frequency::
9.75,10.6GHz
Key words:
Ku Band LNB LNBF
Color:
Grey (Can be customise)
material:
AL
Connector type:
75 Female Connector
packing:
standard export carton for PLL C Band LNB
Product name:
Wholesale High Gain FTA Universal L.O. 12.8GHZ Single Ku Band LNB LNBF
Output:
Single

Quick Details

Place of Origin:
Anhui, China
Brand Name:
BOTE
Model Number:
BT-380B
Input frequency::
10.7-12.75GZH
Output frequency::
950-2150mhz
L.O Frequency::
9.75,10.6GHz
Key words:
Ku Band LNB LNBF
Color:
Grey (Can be customise)
material:
AL
Connector type:
75 Female Connector
packing:
standard export carton for PLL C Band LNB
Product name:
Wholesale High Gain FTA Universal L.O. 12.8GHZ Single Ku Band LNB LNBF
Output:
Single

10.7-12.75GZH   Ku Band 9.75/10.6 G LNB Customized for Project area

Product Description
Model Number
BW-KUFT975
Input Frequency
10.7- 12.75  GHz
Local Frequency
9.75/10.6GHz (Customized frequency)
Output Frequency
950 - 2150 MHz
L.O. Stability
±1 MHz  (- 40 ℃ to +70℃)
Noise Figure
0.5 dB
Gain
65dB typ
Gain Flatness
≤ +1.5 dB
Input VSWR
2.5:1 (max)
Output VSWR
2.0:1 (max)
Output Connector
F-female connector
Output Impedance
75Ω
Cross Polar Isolation
20dB (min)
Image Rejection
45dB (min)
Phase Noise
1) -50dBc / Hz@1kHz (max)
2) -75dBc / Hz@10kHz (max)
3) -95dBc / Hz@100kHz (max)
Control Signals
1) Low Band: Ca or Cb2
2) High Band: Cc or Cb
3) Cc: continues 22 KHz
Supply Voltage
1) Ca: 11.5-14.0V ( Vertival Polarization ) 13V DC Type
2) Cb: 16.0-19.2V ( Horizontal Polarization) 18V DC Type
Direct Current
150mA
Operation Temperature
- 40 ℃ to +70℃
Storage Temperature
- 40 ℃ to +80℃
Relative Humidity
0% ~ 95%

Detailed Images

Factory show:

Welcome to Anhui Bowei Electronics Technology Co., Ltd

Bowei Electronics is a professional manufacture 26 years specialized in LNB, MMDS down converter and Antenna etc. Anhui Bowei Electronics Technology Co., Ltd is a National High-tech Enterprise mainly engaged in the research, development, production, fabrication, marketing of microwave high frequency electronics and over-voltage and over-current protection equipment

Our products command a good market both at home and abroad. Microwave High Frequency Electronics are mainly exported to Europe, Southeast Asia, Middle East, North America etc. 86 countries and areas. In the domestic markets, Anhui Bowei Electronics services for the national Radio and Television“Hu Hu Tong” Household Project and also supports the digital improvement for Regional Radio and TV Cable Network Companies. Meanwhile, Over-voltage and Over-current Protection Equipment are widely distributed around the country and mostly applied in fields of electricity, petroleum, chemistry, metallurgy, cement and steel.

FAQ

1. Are you a factory or trading company?
Re: We are a factory with more than 2 6 years MMDS downconverter and LNB manufacture experiences.

2. What's the Material of your products?
Re:The main material  is Aluminum.


3.Can you make products as our specification providing OEM&ODM service?
Re: Yes. Our Company are a OEM&ODM having a professional engineer team who can design the products as your specification.


4 How does your factory do regarding about quality control ?
Re:Quality is the priority.The products will be examined many times by our technicians before packing
