Quick Details
-
Lift Speed:
-
2.7 m/min
-
Marketing Type:
-
New Product 2022
-
Warranty of core components:
-
other
-
Weight (KG):
-
300 kg
-
After-sales Service Provided:
-
online support
-
Color:
-
Customised
-
Capacity:
-
7.5 Ton
-
Type:
-
Liftling Equipment
-
Power supply:
-
electric
-
Voltage:
-
380v
-
Chain:
-
G80 Chain
-
MOQ:
-
1 Set
-
Packing:
-
Wooden Case Packing
Quick Details
-
Warranty:
-
1 Year
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
DELELIFT
-
Lift Speed:
-
2.7 m/min
-
Marketing Type:
-
New Product 2022
-
Warranty of core components:
-
other
-
Weight (KG):
-
300 kg
-
After-sales Service Provided:
-
online support
-
Color:
-
Customised
-
Capacity:
-
7.5 Ton
-
Type:
-
Liftling Equipment
-
Power supply:
-
electric
-
Voltage:
-
380v
-
Chain:
-
G80 Chain
-
MOQ:
-
1 Set
-
Packing:
-
Wooden Case Packing
Products Description
Clutch:
As emergency overload protection, clutch will functions and motor will slip when abnormal load.
Inverse phase sequence protecting device:
It is the special electrical installation which control the circuit not to work in case of wiring error in the power supply.
Limit switch:
The limit switch device is installed where the weight is lifted on and off to make the motor to stop automatically so as to prohibit the chains from exceeding for safety.
S
ide magnetic braking device:
This device shall realize the instant brake in case of the power dump.
Chain:
Japan FEC80 chain ultra heat-treatable steel alloy chain. Lifting height is against your requirement.
Emergency stop button:
If any emergencies, press it, the motor circuit will be cut off.
Control voltage:
24V, 36V, 48V, 110V are optional, Low control voltage help to prohibit the emergencies occurring in case of hand switch leakage.
Wireless remote control, and overheat protector can be assembled.
Single speed
|
Type
|
Capacity(Ton)
|
Standard Lifting Height(m)
|
Lfting Speed (m/min)
|
Lifting Motor
|
|
|
|
|
Diameter×Chain Fall
|
||||
|
|
|
|
|
Power (Kw)
|
Rotation Speed(r/min)
|
Phases
|
Voltage(V)
|
Frequency(Hz/s)
|
|
||||
|
DLXD00501-2S
|
0.5
|
3
|
6.8
|
0.75
|
1440
|
3
|
200-600
|
50
|
Φ6.3×1
|
||||
|
DLXD0101-2S
|
1
|
3
|
6.6
|
1.5
|
1440
|
3
|
200-600
|
50
|
Φ7.3×1
|
||||
|
DLXD0102-2S
|
1
|
3
|
3.4
|
0.75
|
1440
|
3
|
200-600
|
50
|
Φ6.3×2
|
||||
|
DLXD01501-2S
|
1.5
|
3
|
8.8
|
3.0
|
1440
|
3
|
200-600
|
50
|
Φ10.0×1
|
||||
|
DLXD0201-2S
|
2
|
3
|
6.6
|
3.0
|
1440
|
3
|
200-600
|
50
|
Φ10.0×1
|
||||
|
DLXD0202-2S
|
2
|
3
|
3.3
|
1.5
|
1440
|
3
|
200-600
|
50
|
Φ7.1×2
|
||||
|
DLXD02501-2S
|
2.5
|
3
|
5.4
|
3.0
|
1440
|
3
|
200-600
|
50
|
Φ11.2×1
|
||||
|
DLXD0301-2S
|
3
|
3
|
5.4
|
3.0
|
1440
|
3
|
200-600
|
50
|
Φ11.2×1
|
||||
|
DLXD0302-2S
|
3
|
3
|
4.4
|
3.0
|
1440
|
3
|
200-600
|
50
|
Φ10.0×2
|
||||
|
DLXD0303-2S
|
3
|
3
|
2.2
|
1.5
|
1440
|
3
|
200-600
|
50
|
Φ7.1×3
|
||||
|
DLXD0502-2S
|
3
|
3
|
2.7
|
3.0
|
1440
|
3
|
200-600
|
50
|
Φ11.2×2
|
||||
|
DLXD1004-2S
|
10
|
3
|
2.7
|
3.0×2
|
1440
|
3
|
200-600
|
50
|
Φ11.2×4
|
||||
|
DLXD1004-2SD
|
10
|
3
|
2.7&0.67
|
3.0×2
|
1440&360
|
3
|
200-600
|
50
|
Φ11.2×4
|
||||
Dual speeds
|
Type
|
Capacity(Ton)
|
Standard Lifting Height(m)
|
Lfting Speed (m/min)
|
Lifting Motor
|
|
|
|
|
Diameter×Chain Fall
|
||||
|
|
|
|
|
Power (Kw)
|
Rotation Speed(r/min)
|
Phases
|
Voltage(V)
|
Frequency(Hz/s)
|
|
||||
|
DLXD00501-2SD
|
0.5
|
3
|
6.8&1.7
|
0.75
|
1440&360
|
3
|
200-600
|
50
|
Φ6.3×1
|
||||
|
DLXD0101-2SD
|
1
|
3
|
6.6&1.65
|
1.5
|
1440&360
|
3
|
200-600
|
50
|
Φ7.3×1
|
||||
|
DLXD0102-2SD
|
1
|
3
|
3.4&0.85
|
0.75
|
1440&360
|
3
|
200-600
|
50
|
Φ6.3×2
|
||||
|
DLXD01501-2SD
|
1.5
|
3
|
8.8&2.2
|
3.0
|
1440&360
|
3
|
200-600
|
50
|
Φ10.0×1
|
||||
|
DLXD0201-2SD
|
2
|
3
|
6.6&1.65
|
3.0
|
1440&360
|
3
|
200-600
|
50
|
Φ10.0×1
|
||||
|
DLXD0202-2SD
|
2
|
3
|
3.3&0.82
|
1.5
|
1440&360
|
3
|
200-600
|
50
|
Φ7.1×2
|
||||
|
DLXD02501-2SD
|
2.5
|
3
|
5.4&1.35
|
3.0
|
1440&360
|
3
|
200-600
|
50
|
Φ11.2×1
|
||||
|
DLXD0301-2SD
|
3
|
3
|
5.4&1.354
|
3.0
|
1440&360
|
3
|
200-600
|
50
|
Φ11.2×1
|
||||
|
DLXD0302-2SD
|
3
|
3
|
4.4&1.1
|
3.0
|
1440&360
|
3
|
200-600
|
50
|
Φ10.0×2
|
||||
|
DLXD0303-2SD
|
3
|
3
|
2.2&0.55
|
1.5
|
1440&360
|
3
|
200-600
|
50
|
Φ7.1×3
|
||||
|
DLXD0502-2SD
|
3
|
3
|
2.7&0.67
|
3.0
|
1440&360
|
3
|
200-600
|
50
|
Φ11.2×2
|
||||
|
DLXD1004-2S
|
10
|
3
|
2.7
|
3.0×2
|
1440
|
3
|
200-600
|
50
|
Φ11.2×4
|
||||
|
DLXD1004-2SD
|
10
|
3
|
2.7&0.67
|
3.0×2
|
1440&360
|
3
|
200-600
|
50
|
Φ11.2×4
|
||||
