Quick Details
-
Warranty:
-
12 Months
-
Loading Capacity:
-
2000KG
-
vehicle size:
-
5000mm*1850mm*1550mm
-
vehicle weight:
-
<2000kg
-
lifting height:
-
1600mm
-
lock mode:
-
position lock
-
drive mode:
-
Hydraulic
-
surface treamtment:
-
power coating
-
control power:
-
24v
-
lifting time:
-
25s
-
lowering time:
-
25s
-
Motor power:
-
2.2kw
Quick Details
-
Place of Origin:
-
China
-
Brand Name:
-
Mutrade
-
Model Number:
-
TPTP-2
-
Warranty:
-
12 Months
-
Loading Capacity:
-
2000KG
-
vehicle size:
-
5000mm*1850mm*1550mm
-
vehicle weight:
-
<2000kg
-
lifting height:
-
1600mm
-
lock mode:
-
position lock
-
drive mode:
-
Hydraulic
-
surface treamtment:
-
power coating
-
control power:
-
24v
-
lifting time:
-
25s
-
lowering time:
-
25s
-
Motor power:
-
2.2kw
Products Details
|
Vehicle size
|
5000mmX1850mmX1550mm
|
|
Vehicle weight
|
≤2000Kg
|
|
Lifting height
|
1600mm
|
|
Lock mode
|
Position lock
|
|
Drive mode
|
Hydraulic
|
|
Surface treatment
|
Powder coating
|
|
Control power
|
24V
|
|
Lifting time
|
25S
|
|
Lowering time
|
25S
|
|
Voltage
|
100V-480V, 1 or 3 Phase, 50/60Hz
|
|
Motor power
|
2.2kw
|
Project Case
Related Products
Our Company
Customer Photos
FAQ
1. How many cars could be parked for each set?
2 cars. One is on the ground and another is on the second floor.
2. Is TPTP-2 used indoor or outdoor?
Both of them are available. The finishing is powder coating and plate cover is galvanized, with rust-proof and rain-proof. When used indoor, you need consider the ceiling height.
3. How much is the minimum ceiling height to use TPTP-2?
3100mm is the best height for 2 sedans with 1550mm high. Minimum 2900mm available height is acceptable to fit for TPTP-2.
4. Is the operation easy?
Yes. Keep holding the key switch to operate the equipment, which will stop at once if your hand releases.
5. If the power is off, can I use the equipment normally?
if the electricity failure happens often, we suggest you have a back-up generator, which can make sure the operation if no
electricity.
6. What's the supply voltage?
Standard voltage is 220v, 50/60Hz, 1Phase. Other voltages could be customized according to clients' request.
7. How to maintain this equipment? how often it need the maintenance work?
We can offer you the detailed maintenance guide, and actually the maintenance of this equipment is very simple, for example, keep the round environment tidy and clean, check whether the cylinder is leak oil, the bolt is loose or the steel cable is worn
2 cars. One is on the ground and another is on the second floor.
2. Is TPTP-2 used indoor or outdoor?
Both of them are available. The finishing is powder coating and plate cover is galvanized, with rust-proof and rain-proof. When used indoor, you need consider the ceiling height.
3. How much is the minimum ceiling height to use TPTP-2?
3100mm is the best height for 2 sedans with 1550mm high. Minimum 2900mm available height is acceptable to fit for TPTP-2.
4. Is the operation easy?
Yes. Keep holding the key switch to operate the equipment, which will stop at once if your hand releases.
5. If the power is off, can I use the equipment normally?
if the electricity failure happens often, we suggest you have a back-up generator, which can make sure the operation if no
electricity.
6. What's the supply voltage?
Standard voltage is 220v, 50/60Hz, 1Phase. Other voltages could be customized according to clients' request.
7. How to maintain this equipment? how often it need the maintenance work?
We can offer you the detailed maintenance guide, and actually the maintenance of this equipment is very simple, for example, keep the round environment tidy and clean, check whether the cylinder is leak oil, the bolt is loose or the steel cable is worn
