Grade range: G24 to G100
The Applications: Light duty bearing,Conveyer belt, Bicycle parts,Automobile parts, Slide bearing,Caster wheels, Computer
peripheral products, Toys,Metal milling,Hand tools and etc.
- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
brand king
-
Model Number:
-
4.5mm
-
Material available:
-
AISI1010-1020
-
Grade available:
-
G10-G1000
-
Finishment:
-
Polished;hardened
-
Hardness:
-
NA,HRC58-62
Quick Details
-
Applicable Industries:
-
Manufacturing Plant, Machinery Repair Shops
-
Material:
-
steel
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
brand king
-
Model Number:
-
4.5mm
-
Material available:
-
AISI1010-1020
-
Grade available:
-
G10-G1000
-
Finishment:
-
Polished;hardened
-
Hardness:
-
NA,HRC58-62
|
Factory
|
TAIAN HENGDA STEEL BALL CO LTD.
|
|
Homepage
|
www.steelball0.com,www.hdsteelballs.com
|
|
Product Name
|
4.5mm Steel Balls with Copper-coated
|
|
Material:
|
Low Carbon steel AISI1010,AISI1015 AIS1020
C15 C10 |
|
Size range:
|
4.5mm
|
|
Hardness:
|
G40,G80 G100 G200 G500 G1000
|
|
Hardness:
|
HRC58-62
|
|
Surface:
|
High Polish Mirror Surface
|
|
Application
|
Bearing Accessories,slide rail ball
|
|
Features
|
Strong Wear Resistance
|
|
MOQ
|
1000kgs
|
Grade range: G24 to G100
The Applications: Light duty bearing,Conveyer belt, Bicycle parts,Automobile parts, Slide bearing,Caster wheels, Computer
peripheral products, Toys,Metal milling,Hand tools and etc.
|
Low carbon Steel Material composition.
|
|
|
|
|
|
|
||||||
|
AISI Number
|
C%
|
Si%
|
Mn%
|
S%
|
P%
|
Carburizing
|
||||||
|
AISI1010
|
0.08~0.13
|
0.30Max
|
0.50Max
|
0.06Max
|
0.07Max
|
Case Hardened
|
||||||
|
AISI1015
|
0.13~0.18
|
0.10~0.30
|
0.30~0.60
|
|
0.04Max
|
Case Hardened
|
||||||
manufacturer in China.More than 8,000 square meters and 200 sets of modern and efficient produce equipment ensure annual
production capability of over 5,000 tons steel balls in various material.85% of them are sold to overseas markets in competitive
price and high quality.Precision steel ball in Carbon Steel,Stainless Steel,Chrome Steel Balls and Grinding Balls are the main
products,which range varies from 1mm up to 75mm,which include metric and inch sizes,standard over-sizes and under-sizes.
Title goes here.
At hengda(HD) steel balls manufacturing research, develop and continually test our steel balls to be confident we not only deliver
the high quality steel balls, but the most effective service as well.Engaged in steel balls area since 2005, HD steel balls
manufacturing focus on carbon steel balls, stainless steel balls, high chrome steel balls,bearing steel balls .The diameter from
1.0mm to 25.4mm. Their grade of accuracy is G10-G1000. High precision steel balls are mainly used for ball bearing, while
semi-precision steel balls (grade100 to 1000) are applied to bicycle/motor cycle parts caster wheels,hardware, draw side, toys,
game ball ,wheels, instruments, rail, pumps,polishing, Cosmetics ,the solid smash and so forth. All the steel balls produced
comply with GB/T 308-2002 standard,which equivalent to the international standards ISO3290-1998, AFMBA1989 and DIN5401-93.HD
inspect and detect the roundness, surface Integrity and diameter of steel balls with advanced equipment and consumptive
instrumentation.
