Quick Details
-
Description:
-
BusBar Terminal Block
-
D/C:
-
48V DC
-
Terminal Studs:
-
M6 (1/4") * 6
-
Item:
-
6 Stud Busbar
-
Material of Terminal:
-
Stainless Steel
-
Feature:
-
Nylon Plastic Base
-
Max Continuous Amperage:
-
130A AC, 150A DC
-
Size:
-
150*28*31.5mm
-
Max Voltage:
-
300V AC, 48V DC
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
oengol
-
Model Number:
-
P4R
-
Description:
-
BusBar Terminal Block
-
D/C:
-
48V DC
-
Terminal Studs:
-
M6 (1/4") * 6
-
Item:
-
6 Stud Busbar
-
Material of Terminal:
-
Stainless Steel
-
Feature:
-
Nylon Plastic Base
-
Max Continuous Amperage:
-
130A AC, 150A DC
-
Size:
-
150*28*31.5mm
-
Max Voltage:
-
300V AC, 48V DC
Specification
6 Stud Power Distribution Block Tinned Copper Bus Bar
* Features: Power distribution block also known as battery bus bar, this busbars will come in pairs, includes one red bus bar and one black bus bar.
* Rating: Max voltage: 300V AC, 48V DC. Max continuous amperage: 130A AC, 150A DC.
* Terminals: Each battery distribution block includes -6x M6 terminal studs, suitable for 1/4" insulation ring terminals.
* Application: These 12v bus bars are using copper plates and stainless steel terminals as conductors, which makes it can work in extreme environment, suitable for automotive, car, truck, marine, boat, yacht, etc.
* What you get: Positive distribution block x 1, ground distribution block x 1, 4 x screws,
* Rating: Max voltage: 300V AC, 48V DC. Max continuous amperage: 130A AC, 150A DC.
* Terminals: Each battery distribution block includes -6x M6 terminal studs, suitable for 1/4" insulation ring terminals.
* Application: These 12v bus bars are using copper plates and stainless steel terminals as conductors, which makes it can work in extreme environment, suitable for automotive, car, truck, marine, boat, yacht, etc.
* What you get: Positive distribution block x 1, ground distribution block x 1, 4 x screws,
|
Item
|
Daiertek Auto Car 150A Heavy Duty 6*M6 Studs 304 Stainless Steel Bus Bar Terminal Distribution Block With Cover
|
|
Part NO
|
BB150-T6M6-C
|
|
Number of Contacts
|
1-6
|
|
Conductor Size
|
12`28AWG
|
|
Terminal Studs
|
6*M6 (1/4")
|
|
Max Voltage
|
300V AC, 48V DC
|
|
Max Continuous Amperage
|
130A AC,1 50A DC
|
|
Material
|
Nylon Plastic Base + Stainless Steel Terminals
|
|
Color
|
Red/Black
|
|
Size
|
150*28*31.5mm
|
|
Usage
|
Distribution Line suitable for automotive, car, truck, marine, boat, yacht, etc.
|
