Quick Details
-
Warranty:
-
12 months
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
VLAIS
-
Model Number:
-
CP-C150
-
Speed:
-
1500RPM
-
Weight:
-
1670KG
-
Engine type:
-
Water cooled, 6 Cylinder vertical in line, 4 stroke, turbo charged
-
Bore*stroke(mm):
-
102*120
-
Engine Model:
-
Cummins 6BTAA5.9-G12
-
Alternator brand:
-
Stamford/ Marathon/ Leroysomer
-
Alternator model and type:
-
CP-274F, brushless, all copper
-
Control Panel:
-
Mebay
-
Starting system:
-
electric starter
-
Fuel Consumption(L/kw.h):
-
0.26L/kw h
-
Noise level:
-
65-68dBA@7m
-
Displacement:
-
5.9L
-
Certification:
-
CE;ISO9001
Quick Details
-
Rated Voltage:
-
220V/380V
-
Rated Current:
-
228A(380V)
-
Frequency:
-
50HZ
-
Warranty:
-
12 months
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
VLAIS
-
Model Number:
-
CP-C150
-
Speed:
-
1500RPM
-
Weight:
-
1670KG
-
Engine type:
-
Water cooled, 6 Cylinder vertical in line, 4 stroke, turbo charged
-
Bore*stroke(mm):
-
102*120
-
Engine Model:
-
Cummins 6BTAA5.9-G12
-
Alternator brand:
-
Stamford/ Marathon/ Leroysomer
-
Alternator model and type:
-
CP-274F, brushless, all copper
-
Control Panel:
-
Mebay
-
Starting system:
-
electric starter
-
Fuel Consumption(L/kw.h):
-
0.26L/kw h
-
Noise level:
-
65-68dBA@7m
-
Displacement:
-
5.9L
-
Certification:
-
CE;ISO9001
Product Description
| Diesel Generator Data Sheet | |
| Generator Model | CP-C150 |
| Rated Power | 120KW/150KVA |
| Rated Voltage | 220V/380V(Voltage can be customized) |
| Frequency | 50HZ |
| Power Factor | COS=0.8 |
| Weight(kg) | 1670KG |
| Cooling Method | Water-cooled |
| Start-up Mode | DC 36V/Electric Start |
| ATS | Can be retrofitted additionally |
| Diesel Engine Data Sheet | |
| Brand | Cummins |
| Model | 6BTAA5.9-G12 |
| Number of Cylinder | 6 Cylinder Vertical in Line |
| Speed | 1500RPM(50hz) |
| Cycle | 4 Stroke |
| Aspiration | Turbo charged |
| Cooling Method | Water-cooling |
| Bore*Stroke(mm) | 102*120 |
| Compression Ratio | 17.3:1 |
| Speed Governor | Electronic |
| Fuel Consumption | 203g/kw h |
| Fuel Tank | 8-10 Running Time(can be customized) |
| Alternator Data Sheet | |
| Brand | Stamford/ Marathon/ Leroysomer |
| Model | CP-274F |
| Connecting Type | Single Phase/Three Phase and Four Wires |
| Exciter Type |
Single bearing, brushless, self-excited |
| Protection Grade | IP23 |
| Insulation Class | H |
| Exciter Type | Brushless, Self-excited, AVR Controller |
| Altitude | ≤1000m |
| Controller | |
| Optional Controller Brand | Mebay(Can be upgraded to Deepsea/ComAp/Smartgen) |
