Quick Details
-
Place of Origin:
-
Chongqing, China
-
Brand Name:
-
Senci
-
Dimension(L*W*H):
-
540*540*500 mm
-
Weight:
-
42kg
-
Rated power/speed:
-
16.0-3600
-
Warranty of core components:
-
not available
-
Key Selling Points:
-
OHV. Twin Duplex Carburator
-
Engine type:
-
Air-cooled 4-stroke two cylinder
-
Starting system:
-
Recoil/E-start
-
Bore*Stroke(mm*mm):
-
80x74
-
Ignition type:
-
T.C.I
-
Compression:
-
8:8:1
-
Rated output(kw-r/min):
-
16.0/3600
-
Max. Torque(N.m-r/min):
-
42.0/2500
-
Business type:
-
manufacture, marketing, export, OEM
-
Fuel optional:
-
Gasoline
Quick Details
-
Displacement:
-
744cc, 744cc
-
Emission Standard:
-
Other
-
Power:
-
16kw
-
Place of Origin:
-
Chongqing, China
-
Brand Name:
-
Senci
-
Dimension(L*W*H):
-
540*540*500 mm
-
Weight:
-
42kg
-
Rated power/speed:
-
16.0-3600
-
Warranty of core components:
-
not available
-
Key Selling Points:
-
OHV. Twin Duplex Carburator
-
Engine type:
-
Air-cooled 4-stroke two cylinder
-
Starting system:
-
Recoil/E-start
-
Bore*Stroke(mm*mm):
-
80x74
-
Ignition type:
-
T.C.I
-
Compression:
-
8:8:1
-
Rated output(kw-r/min):
-
16.0/3600
-
Max. Torque(N.m-r/min):
-
42.0/2500
-
Business type:
-
manufacture, marketing, export, OEM
-
Fuel optional:
-
Gasoline
|
Model
|
SC690
|
SC750
|
SV1000
|
||
|
Engine type
|
Single cylinder, 4 Stroke, Forced Coolling OHV
|
|
|
||
|
Bore x Stroke (mm)
|
78x72
|
80x74
|
90x78.5
|
||
|
Displacement
|
688cc
|
744cc
|
999cc
|
||
|
HP
|
24
|
27
|
35
|
||
|
Compression
|
8.5:1
|
8.8:1
|
8.8:1
|
||
|
Starting method
|
Recoil/E-start
|
|
|
||
|
Ignition method
|
Transistorized ignrtion
|
|
|
||
|
Lubrication method
|
Splash
|
|
|
||
|
Rated output(Kw-r/mim)
|
14.0-3600
|
16.0-3600
|
24.0-3600
|
||
|
Max torque(N.m-r/mln)
|
42.0-2500
|
48.0-2500
|
70.0-2500
|
||
|
Mln.fuel consumptlon(g/Kw.h)
|
<360
|
<360
|
<360
|
||
|
Dimensiones L*W*H (mm)
|
510*400*565
|
540*540*500
|
610*615*620
|
||
|
Net weight (kgs)
|
42.0
|
42
|
60
|
||
|
Loading Qty (20GP/40HQ)
|
240/508
|
160/440
|
81/228
|
||
Two Cylinder 4 Stroke Mechanical Engine With Ignition Coil 16Kw
