Quick Details
-
Model Number:
-
C6
-
Grade:
-
TiNi
-
Ti (Min):
-
50%
Quick Details
-
Application:
-
Eyewear industry
-
Place of Origin:
-
Shaanxi, China
-
Brand Name:
-
Triad
-
Model Number:
-
C6
-
Grade:
-
TiNi
-
Ti (Min):
-
50%
Products Description
|
Important detail
|
Superelastic memory alloy gasket, the finished product phase change temperature is low, above 0℃ to maintain good superelasticity.
|
|
Product name
|
Titanium-nickel shape memory alloy gasket
|
|
Brand name
|
Triad
|
|
Model number
|
C4
|
|
place of origin
|
Xi 'an
|
|
material
|
TiNi
|
|
Apply
|
Used as a spring cushion on mechanical equipment
|
|
shape
|
Conical plate
|
|
Length
|
M5/M8/M10/M12/M14/M16/M18/M20
|
|
Stress-strain Diagram of Superelastic Nitinol
|
|
|
|
|
|
|
||||||
|
Test Date:2022-04-09
Grade: C6 |
|
|
Test Standard:GB/T 228-2010
Temp.: 30°C |
|
|
Batch No.: 430*6
|
||||||
|
|
Specification
|
Original gauge length(mm)
|
Tensile strength
|
UPS
|
LPS
|
ELr
|
||||||
|
Unit
|
mm
|
mm
|
Mpa
|
Mpa
|
Mpa
|
%
|
||||||
|
Sample 1
|
0.588
|
50
|
640
|
608
|
403
|
0.2
|
||||||
|
Stress-strain Curve
|
|
|
|
|||
|
Sample batch number
|
2021/4/28
|
Sample serial number
|
Not processed (C6 Φ0.7)
|
|||
|
Original gauge length(mm)
|
50
|
Cross-sectional area (mm²)
|
0.38
|
|||
|
Test Temperature (°C)
|
20
|
Specification (mm)
|
/
|
|||
|
Elongation at break (%)
|
16
|
Tensile strength (Mpa)
|
1038
|
|||
|
Percent Reduction in Area
|
/
|
Non proportional elongation (Mpa)
|
520
|
|||
|
Elastic Modulus (Gpa)
|
27.52
|
The yield ratio
|
0.48
|
|||
