Quick Details
-
Detection method:
-
customized motion capture
-
Single System Resolution:
-
1024*768
-
Detection Algorithms:
-
Hand/Head/ Full body tracking
-
Display Support:
-
All kinds projectors
-
Interaction Modes:
-
Multi People interaction
-
SDK support:
-
YES
-
Power-supply:
-
110-220V
Quick Details
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
CHARIOT
-
Model Number:
-
IPS-F
-
Detection method:
-
customized motion capture
-
Single System Resolution:
-
1024*768
-
Detection Algorithms:
-
Hand/Head/ Full body tracking
-
Display Support:
-
All kinds projectors
-
Interaction Modes:
-
Multi People interaction
-
SDK support:
-
YES
-
Power-supply:
-
110-220V
Chariot interactive floor projection system is unusual, exciting and modern. It combines intuitive human body motion
with floor and surface areas, can transforms an ordinary floor/wall into an exciting, entertaining, and educating experience.
Chariot interactive floor projection system can also provide you an edge blending technology, this technology let
smaller images into one larger image, can be used in a long bending surface.
|
|
|
| Version | Tips | System Includes | |
| Basic version | If you have your own projector and computer, you can choose this version, but you'd better a professional technical person. |
Software - Chariot interactive projection software - 60 effects for free - Software SDK (Flash,C/C++,Java) - Windows 7/8 O.S |
Hardware
- Customized IR camera & Brackets - Power adapter - Video capture USB card & Video cable - USB dongle - User manual & warranty |
| All-in-one version | It is a plug in and play version, very easy to install. It is the best choice for all people. |
Software - Chariot interactive projection software - 60 effects for free - Software SDK (Flash,C/C++,Java) - Windows 7/8 O.S |
Hardware
-Mini PC - Projector -Customized IR camera & Brackets -Wireless Mouse & Keyboard -Power adapter -Video capture USB card & Video cable -USB dongle -User manual & warranty |
| Various kind of 3D and Flash effects: | More than 100 effects have been developed by the professional designer. |
| Easy Customization: | Image, audio, video, text and more elements can be easily customized by yourself. |
| Software SDK pack: | Let you developed brand new effects of your own. You can develop your own effects by C/C++, jAVA, OpenGL, Direct 3D, Unity 3D, Flash Action Script and so on. |
| Time management function: | Each effects can be run according to the setting time. |
| Remote control supported: | The interactive floor software can be managed remotely from anywhere in the world. |
| Multiple display supported: | Not only projector, but also LCD screen, digital video wall, and much more display screen can be used in the interactive system. |
| Flexbile bracket: | The design of moving bracket makes your installation even greater flexibility. |
| Perfect Warranty & 24*7 Technical support: |
Free of life time for software. One year for hardware. Our Technical Support engineers are available round the clock for your installation, content and technical queries. |
| Global delivery: |
Various international company is now cooperating with ChariotTech. We will choose the best one for you to make sure you will get the products asap. Simple and lightweight package. Make sure you will receive an intact system with lowest shipping cost. |
| Detection method: | Proprietary motion sensor. |
| Interaction modes: | Single Person Interaction Mode and Multi Prople Interaction Mode supports up to 50 concurrent users. |
| Display support: | Supports all projectors, LCD screen, etc. |
| Detection algorithms: | Hand/Head precision tracking, Full body tracking. |
| Sensor cable: |
10m standard length. Special length up to 80m available on request. |
| SDK interface: | C/C++, NET, Java, Open GL, Direct 3d, Unity 3D, Flash, etc. |
| Operating system: | Windows 7/8 |
| Recommended PC: |
CPU: 1.6GHZ Graphic card: HD Memory: 4G DDR3 Hard Disk: SSD 128G N3700 |
| Power supply: | 220v & 110v |
| Sensor positioning: | A minimum of 2m and a maximum of 6m from detection area. |
| Response time: | < 15 milliseconds for light correction and interaction Calibration. |
| Display system resolution: | 1024*768 |
| Operating temperature: | 0 to + 40℃ |
Q1: How many effects are available?
A: We have more than 100 effects, you can choose 60 effects for free.
Q2: Can I buy any other projector by myself ?
A: Yes. Just need provide us with the dimensions of your projector and we will customize the system according to your needs.
Q3: If I buy the basic version,can you teach me how to install the interactive floor system?
A: Yes, we will provide you with a detailed user manual and an installation video.
Q4: Can you design new effects for me?
A: Yes. What you can image, what we can design.
Q5: Can I use my own images?
A: Yes, Simply click "customize effects" to enter the customization window of each effect.
Q6: What is the delivery time?
A: Just 3-5 working days after payment.
